DIAGNOSTI CS PROFLOW 39.12 Technical Reference Manual Chapter Issue 4, Aug 14 ProFlow Fitted Indication of electrical connection of ProFlow to the printer software. Paste Cassette Low ProFlow paste low sensor activate d …
DIAGNOSTICS
PROFLOW
Chapter Issue 4, Aug 14 Technical Reference Manual 39.11
PROFLOW Selecting this diagnostics module opens the following window:
The following icons are displayed:
Next/Previous moves the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight
bar.
Exit returns operation to the module diagnostics page.
Home ProFlow Selecting this diagnostic function drives the ProFlow unit up to the home
position.
Drive System to
Contact Height
Selecting this diagnostic function drives the ProFlow unit onto the stencil, (a
slight pressure seal, is made between the ProFlow transfer head and the
stencil). There is no pressure applied to the paste cassette.
Drive System to
Print Height
Selecting this diagnostic function drives the ProFlow transfer head down to
printing pressure (as setup in the Edit Data board file). There is no pressure
applied to the paste cassette at this time.
Drive System
Using Jog Buttons
Selecting this diagnostic function enables the ProFlow unit to be moved up or
down by means of the jog buttons.
Toggle Air
Pressure
Selecting this diagnostic function initiates pressure onto the paste cassette.
Before initiating pressure to the paste cassette, the transfer head must be in
contact with, and have an adequate seal with the stencil. A warning is displayed
if toggle air pressure is selected with the transfer head off the stencil.
Toggle Auto Drip
Tray
Selecting this diagnostic function alternately energizes and de-energizes the
auto drip tray, displaying On when extended and Off when retracted. Reads Not
Fitted when feature is not installed.
Pressure Reading This diagnostic function continuously displays the current pressure in kg,
exerted from the squeegee pressure load cell onto the ProFlow unit.
ProFlow Diagnostics
11.42Kg
857
Home ProFlow
Drive System to Contact Height
Drive System to Print Height
Drive System Using Jog Buttons
Toggle Air Pressure
Toggle Auto Drip Tray
Pressure Reading:
ProFlow Fitted
Paste Cassette Low
ProFlow Pressure Regulator Fitted
Auto Drip Tray Retracted
ProFlow Transfer Material Level Reading:
OFF
ON
ON
OFF
OFF
ON
Run
Diagnost
Next
Previous
Exit
DIAGNOSTICS
PROFLOW
39.12 Technical Reference Manual Chapter Issue 4, Aug 14
ProFlow Fitted Indication of electrical connection of ProFlow to the printer software.
Paste Cassette
Low
ProFlow paste low sensor activated (on), indicating paste low or empty or,
deactivated (off).
ProFlow Pressure
Regulator Fitted
Switched to OFF indicates that the ProFlow unit is fitted with a mechanical
pressure regulator control. Switched to ON indicates that the software address-
able regulator control is activated, I ProFlow not fitted with mechanical pressure
regulator.
Auto Drip Tray
Retracted
This diagnostic function continuously displays the status of the auto drip tray
retracted sensor. Reads Not Fitted when feature is not installed.
ProFlow Paste
Level Reading
This diagnostic function continuously displays the current ProFlow paste level
sensor analogue value.
DIAGNOSTICS
SQUEEGEE
Chapter Issue 4, Aug 14 Technical Reference Manual 39.13
SQUEEGEE Selecting this diagnostics module opens the following window:
The following icons are displayed:
Next/Previous moves the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight
bar.
Exit returns operation to the module diagnostics page.
Home Front
Squeegee
Selecting this diagnostic function drives the front squeegee upwards to its home
position, as detected by its home sensor.
Home Rear
Squeegee
Selecting this diagnostic function drives the rear squeegee upwards to its home
position, as detected by its home sensor.
Front Squeegee to
Dwell Height
Selecting this diagnostic function drives the front squeegee to a position clear
of the top of the stencil (default is 30mm).
Rear Squeegee to
Dwell Height
Selecting this diagnostic function drives the rear squeegee to a position clear of
the top of the stencil (default is 30mm).
Rear Squeegee to
Flood Height
Selecting this diagnostic function drives the rear squeegee to the height set by
the flood reference height parameter.
Drive Front
Squeegee Using
Jog Buttons
Selecting this diagnostic function enables the front squeegee to be driven up
and down using the jog buttons. The right jog button drives the squeegee down
and the left jog button drives it up, stopping immediately the button is released.
‘Use the Left Jog Button to move the Squeegee upwards, and the Right
jog Button to move it downwards.’ is displayed in the message prompt box.
Squeegee Diagnostics
Pressure Reading
Roll Height Monitor Laser Receiver
Auto Drip Tray Retracted
22.356 kg
Home Front Squeegee
Home Rear Squeegee
Front Squeegee To Dwell Height
Rear Squeegee To Dwell Height
Rear Squeegee To Flood Height
Drive Front Squeegee Using Jog Buttons
Drive Rear Squeegee Using Jog Buttons
Toggle Roll Height Monitor Laser
Toggle Auto Drip Tray
ON
ON
ON
ON
Run
Diagnost
Next
Previous
Exit
