DIAGNOSTICS

VACUUM TOOLING

39.32 Technical Reference Manual Chapter Issue 4, Aug 14

VACUUM TOOLING

Selecting this diagnostics module opens the following window:

The following icons are displayed:

Run Diagnost activates the diagnostic function, as selected by the highlight

bar.

Exit returns operation to the module diagnostics page.

Toggle Vacuum

Pump

Selecting this diagnostic function alternately switches the vacuum pump on and

off, while continuously displaying the current status.

Vacuum Tooling

Sensor

This diagnostic function continuously displays the status of the vacuum tooling

sensor.

Vacuum Tooling Diagnostics

OFF

Vacuum Tooling Sensor

Toggle Vacuum Pump

Run

Diagnost

Exit

DIAGNOSTICS

PASS THROUGH RAILS

Chapter Issue 4, Aug 14 Technical Reference Manual 39.33

PASS THROUGH RAILS

Selecting this diagnostics module opens the following window:

NOTE

Rail Clash Sensor is not displayed on the front print machine.

The following icons are displayed:

Next/Previous moves the highlight bar up and down the list of selectable

diagnostic functions.

Run Diagnost activates the diagnostic function, as selected by the highlight

bar.

Exit returns operation to the module diagnostics page.

Adjust opens the following window:

The following icons are displayed:

Next/Previous moves the highlight bar up and down the list of diagnostic

parameters.

Incr./Decr. changes the value of the selected diagnostic parameter.

Exit returns operation to the rail system diagnostics page.

NOTE

These parameters are used in diagnostics only and have no affect on the

product board file.

Rail Clash Sensor

Rail Move Inhibit

FMI Inhibit

Cycle Count Done :- 0, To go :- 50

OFF

Home Rail Width

Drive Rail To Board Width

Set Rail Board Width Calibration

Drive Rail Width Using Two Button Control

Cycle Rails

Drive Rail To Max Board Width

Pass Through Rail Diagnostics

OFF

Run

Diagnost

NextAdjust

Exit

Pass Through Rail Test Parameters

Pass Thr Board Width

CYCLE COUNT

100.0

Cycles

Next Incr. Decr.

Exit

DIAGNOSTICS

PASS THROUGH RAILS

39.34 Technical Reference Manual Chapter Issue 4, Aug 14

Home Rail Width Selecting this diagnostic function drives the moving rail to its home position as

determined by its home sensor.

Drive Rail to Board

Width

Selecting this diagnostic function drives the moving rail to the width set by the

board width parameter.

Drive Rail to Max

Board Width

Selecting this diagnostic function drives the moving rail to the maximum board

width.

Set Rail Board

Width Calibration

Selecting this diagnostic function opens the following window:

The following icons are displayed:

This diagnostic allows for a ±6mm offset to be applied to the width of the rails

set by the Board Width parameter.

Move drives the rails by the amount set by the rail width parameter.

Set overwrites the board width configuration figure by the value set by the rail

width offset parameter.

Incr./Decr. changes the value of the rail width offset parameter.

Cancel returns the operation to the rail system diagnostic page.

Drive Rail Width

Using Two Button

Control

Selecting this diagnostic function drives the rail width motor using the jog

buttons, stopping immediately the button is released. The message ‘Use left

jog button to move rail to maximum separation, or use right jog button to

move rail to minimum separation’ is displayed in the message prompt box.

Cycle Rails Selecting this diagnostic function drives the moveable rail from the home

position to the minimum board width and back to the home position. ‘Cycling

Rails....’ is displayed in the message prompt box.

Rail Clash Sensor This diagnostic function continuously displays the status of the rail clash sensor.

Rail Move Inhibit This diagnostic function continuously displays the status of the rail move inhibit.

The rail move is inhibited if:

• A board is detected on the rails

• The printer is in the process of transferring a board from the upline machine

FMI Inhibit This diagnostic function continuously displays the status of the FMI inhibit. The

FMI inhibit is activated by the software prior to the rail moving to prevent a board

entering the rails from the upline machine.

RAILWIDTH OFFSET

0.00

Move

Incr.

Set

Decr.

Cancel
