TRANSPORTATION - MINOR RELOCATION MACHINE HEIGHT AND LEVELLING 41.24 Technical Reference Manual Chapter Issue 4, May 19
TRANSPORTATION - MINOR RELOCATION
MACHINE HEIGHT AND LEVELLING
Chapter Issue 4, May 19 Technical Reference Manual 41.23
30. Rotate the stopper bolts by hand until they make contact with the opposing
block, and then secure them using the locknuts.
31. Move Machine A back into position locating foot (3) into V-Block.
32. Position locating foot (4) against Locating Block.
33. Recheck the machine is level.
34. Recheck the machine height has not been disturbed.
Power Up On completion of relocation, carry out the procedure in the Transportation -
Power Up chapter.
Stopper Bolts
TRANSPORTATION - MINOR RELOCATION
MACHINE HEIGHT AND LEVELLING
41.24 Technical Reference Manual Chapter Issue 4, May 19
TRANSPORTATION - MAJOR RELOCATION
PREPARATION
Chapter Issue 5, Nov 19 Technical Reference Manual 42.1
CHAPTER 42 TRANSPORTATION - MAJOR RELOCATION
PREPARATION
The following chapter describes the recommended procedure to prepare the
machine for transportation from its originally installed position to minimize the
risk of damage to the machine during transportation.
This procedure is fully detailed, illustrating every aspect of transporting a
machine safely when:
• Machine relocation is to another site outside the original factory
• The machine is being stored
• If the machine has to experience any substantive shocks or vibration
NOTE
If the machine is being stored or moved to another location, it is recommended
that the machine is packaged in its original packing crate.
Machine Prior to installing transit brackets to the machine ensure the following:
1. With power applied to the machine:
a. Drive the rails to 40mm board width.
b. Home the stencil actuators.
2. Shut down the printer software.
3. Switch off and disconnect the electrical power.
4. Disconnect the air supply.
5. Remove/open the rear printhead cover.
6. On Type 1 or 2 cover machine, remove the two upper side panels as detailed
in the Covers chapter.
