SENSORS TEMPERATURE AND HUMIDITY S ENSOR 40.20 Technical Reference Manual Chapter Issue 6, May 19
SENSORS
TEMPERATURE AND HUMIDITY SENSOR
Chapter Issue 6, May 19 Technical Reference Manual 40.19
TEMPERATURE AND HUMIDITY SENSOR
The temperature and humidity sensor is an integral part of the print carriage
I/O Node 3 PCB and as such there is no adjustment and setting available for
this sensor.
SENSORS
TEMPERATURE AND HUMIDITY SENSOR
40.20 Technical Reference Manual Chapter Issue 6, May 19
TRANSPORTATION - MINOR RELOCATION
INTRODUCTION
Chapter Issue 4, May 19 Technical Reference Manual 41.1
CHAPTER 41 TRANSPORTATION - MINOR RELOCATION
INTRODUCTION The following three chapters describe the recommended procedure for moving
or storing the machine:
• Minor Relocation - Moving the machine to another area within the factory
• Major Relocation - Moving the machine to another factory or storage
• Power Up - Must be performed after Minor or Major Relocation
The following procedure is utilized to minimize the risk of damage to the
machine when:
• The machine is brought out of line for servicing or fault rectification.
• The machine is being relocated a short distance from its original position,
ie within the confines of the factory on a pallet truck or similar manually
operated machine.
For major relocation, factory to factory moves, long term storage or where
excessive noise or vibration may affect the printer, refer to Transportation -
Major Relocation.
Machine
Preparation
1. With power applied to the machine, home the stencil actuators.
2. Switch OFF and disconnect the electrical power.
3. Disconnect the pneumatic supply.
4. Remove/open the rear printhead cover as detailed in the Covers chapter.
5. On Type 1 cover machines, remove the two upper side panels as detailed
in the Covers chapter.
