HERMES SETUP 37.12 Technical Reference Manual Chapter Issue 2, Nov 19 1. Select Maintenance . 2. Select Machine Setup . 3. Select Barcodes . 4. Select Barcode Source . 5. Select Hermes . 6. Select Accept . 7. Select Exit…
HERMES
SETUP
Chapter Issue 2, Nov 19 Technical Reference Manual 37.11
25. Set the IP Address and Port Number for the printer on the upline and
downline stations.
NOTE
See the Technical documentation for the upline and downline machines for
guidance.
Remote Setup In order to configure Hermes remotely via a network, Hermes Remote configu-
ration must be enabled and an Ethernet connection to the network established.
The following procedure details setting the printer software to remote.
NOTE
For information on the location and connection for the Ethernet cable contact
the Network Administrator / Line Controller. For information on the location of
the Ethernet connection socket on the printer refer to the Networking chapter of
this manual.
1. Select Maintenance.
2. Select Machine Setup.
3. Select Data Comms.
4. Select Hermes.
5. Select Hermes Remote Configuration.
6. Select Enabled.
7. Select Accept.
8. Select Back.
9. Select Back.
10. Select Back.
Barcode Source The Barcode source must be set to Hermes.
NOTE
If the printer is the first station in the SMT line with barcode reading functionality
then the Barcode source is to be set to remote.
HERMES
SETUP
37.12 Technical Reference Manual Chapter Issue 2, Nov 19
1. Select Maintenance.
2. Select Machine Setup.
3. Select Barcodes.
4. Select Barcode Source.
5. Select Hermes.
6. Select Accept.
7. Select Exit.
8. Select Back.
9. Select Back.
HERMES
TESTING THE CONNECTION
Chapter Issue 2, Nov 19 Technical Reference Manual 37.13
TESTING THE CONNECTION
Pinging the
Network
To test if the DEK printer is connected to the network, you can ‘Ping’ the network
using the following procedure:
1. From the Windows desktop, select Start - Run and enter CMD in the box
labelled ‘Open:’.
2. Select OK.
3. Type Ping <Server IP Address or Computer Name>.
NOTE
The network administrator can supply an IP Address or computer name to
ping.
4. If the ping is successful the reply shall contain information of the form: Reply
from 195.213.112.69: bytes=32 time<10ms TTL=128.
The installation of the printer to the company network has been successful.
