User Manual SIPLACE SX4/DX4 3 Technical data and assemblies
From software version SC.706.xx Version 06/2012 EN 3.1 Performance data
99
3.1.3.2 SIPLACE DX4
3
Single conveyor Flexible dual con-
veyor
Dual conveyor in sin-
gle conveyor mode
Board dimensions
(length x width
a
)
Standard:
50 mm x 50 mm to
285 mm x 560 mm
50 mm x 50 mm to
285mm x 325mm
50 mm x 50 mm to
285 mm x 560 mm
Option: “Long Board 380
b
50 mm x 50 mm to
380 mm x 560 mm
50 mm x 50 mm to
450mm x 325mm
50 mm x 50 mm to
450 mm x 560 mm
Option: “Long Board 550
b
50 mm x 50 mm to
550 mm x 560 mm
-- --
stationary conveyor side Right or left Right, left or outer
Automatic electrical width adjustment Yes
PCB thickness
Standard: 0.3 mm to 4.5 mm
PCB warpage See page 140
PCB weight
c
standard max. 2.0 kg max. 1.0 kg max. 2.0 kg
Clearance on PCB underside
Standard stopper:
Up to 25 mm
PCB conveyor height
Option:
Standard:
SMEMA option:
900 mm
930 mm
950 mm
type of interface:
Standard:
Option:
SMEMA
Siemens
Component-free PCB handling edge 3 mm
PCB changeover time
Single conveyor
Dual conveyor
d
< 1.5 seconds
0 seconds
a) When using board widths > 450 mm, make sure that the peripheral modules can also process these board widths.
b) "Long Board" option with restrictions.
c) The board weight value refers to the weight of the board plus the weight of the components.
d) 0 seconds in asynchronous mode, otherwise 1.5 seconds.
3 Technical data and assemblies User Manual SIPLACE SX4/DX4
3.1 Performance data From software version SC.706.xx Version 06/2012 EN
100
3.1.4 Component feeding
3.1.4.1 SIPLACE SX4
3
3.1.4.2 SIPLACE DX4
3
Tape reel diameter
standard
maximum
to 432 mm (17“)
483 mm (19“)
Max. component feeding
(4 X component trolleys on the SX4)
Location 1 and 3:
Location 2 and 4:
148 8 mm X feeder modules
80 feeders with 8 mm
68 feeders with 8 mm
Component trolley changeover time < 1 minute
Feeder module types Tape feeder modules, linear vibratory feeders, dip modules,
application-specific OEM feeder modules
Tape reel diameter 178 mm to 381 mm (7“ - 15“)
Max. component feeding
(Four DX tables for SIPLACE DX4)
Location 1 and 3:
Location 2 and 4:
74 tape feeder modules, each with 2x8 mm X
40 feeder modules, each with 2x8 mm X
34 feeder modules, each with 2x8 mm X
Feeder module types (SIPLACE X) Tape feeder modules
User Manual SIPLACE SX4/DX4 3 Technical data and assemblies
From software version SC.706.xx Version 06/2012 EN 3.2 Ambient conditions and connection values
101
3.2 Ambient conditions and connection values
3.2.1 Ambient conditions for the packaging, transportation and storage
3
3.2.2 Environmental conditions for machine operation
3
3.2.3 Electrical ratings
3
Temperature range Between -25°C and 55°C
Atmospheric humidity Up to 95%
Ambient pressure Up to 3000 m height without pressure equalization
Room temperature Between 15°C and 35°C
Atmospheric humidity 30% to 75%
(on average not higher than 45%, so that there is no risk of
condensation on the machine.)
Ambient pressure > 750 mbar (corresponds to 2,500 m above mean sea level)
Electrical ratings
Supply voltage Fuse
Main power supply
3 x 200 V~ ± 10 %; 50 Hz (North Japan)
3 x 220 V~ ± 10 %; 60 Hz (South Japan)
3 x 208 V~ ± 10 %; 50/60 Hz (U.S.A)
3 x 230 V~ ± 10 %; 50/60 Hz
3 x 380 V~ ± 10 %; 50/60 Hz
3 x 400 V~ ± 10 %; 50/60 Hz (Europe)
3 x 415 V~ ± 10 %; 50/60 Hz
3 x 25 A up to max. 3 x 32 A
3 x 25 A up to max. 3 x 32 A
3 x 25 A up to max. 3 x 32 A
3 x 25 A up to max. 3 x 32 A
3 x 16 A
3 x 16 A
3 x 16 A
Mains power connec-
tion
Cable 5 x 4 mm² 5 x 32 A (3 x 200 V~ / 208 V~ / 220 V~/ 230 V ~)
Cable 5 x 4 mm² with CEKON connector 5 x 16 A (3 x 380 V~ / 400 V~ / 415 V~)
Energy consumption
Energy consumption
Without vacuum pump
Energy consumption
with vacuum pump
a
Nominal apparent
power
4.70 kVA 6.00 kVA
Nominal active power
2.70 kW 3.45 kW
a) Vacuum pump is standard for DX4. Vacuum pump for C&P20 head only.
