6 Station extensions User Manual SIPLACE SX4/DX4 6.9 Component camera for the MultiStar From software version SC.706.xx Version 06/2012 EN 334 6.9 Component camera for the MultiS t ar 6.9.1 Component camera, st ationary …
User Manual SIPLACE SX4/DX4 6 Station extensions
From software version SC.706.xx Version 06/2012 EN 6.8 Component camera for the TwinStar, FC camera
333
6.8.3 Technical data
6
6
6
6
6.8.4 Position
The position of the stationary component cameras and the associated configurations are de-
scribed
in section 3.8.2
, from page 143.
Component dimensions 0.2 mm x 0.2 mm up to 16 mm x 16 mm for single component
measurement
Component range 0402 to SO, PLCC, QFP, sockets, plugs, BGA, special components,
bare dies, flip-chips, shields
Min. lead pitch 0.25 mm
Min. lead width 0.1 mm
Min. ball pitch 0.14 mm
Min. ball diameter 0.08 mm
Field of vision 19.4 mm x 19.4 mm
Method of illumination Front-illumination (6 levels, programmable as required)
6 Station extensions User Manual SIPLACE SX4/DX4
6.9 Component camera for the MultiStar From software version SC.706.xx Version 06/2012 EN
334
6.9 Component camera for the MultiStar
6.9.1 Component camera, stationary, P&P, type 33, 55 x 45, digital
Item no. 00519902-xx Stationary camera for the CPP head, type 33
6
Fig. 6.9 - 1 Structure for the stationary P&P component camera, type 33, 55 x 45, digital
(1) Camera housing with integral camera and camera amplifier
(2) Glass plate - over the illumination and lens levels
User Manual SIPLACE SX4/DX4 6 Station extensions
From software version SC.706.xx Version 06/2012 EN 6.9 Component camera for the MultiStar
335
6.9.1.1 Technical data
6
6
6.9.1.2 Position
The position of the stationary component cameras and the associated configurations are de-
scribed
in section 3.8.2
, from page 143.
Component dimensions 0.5 mm x 0.5 mm to 55 mm x 45 mm
Component range 0402, MELF, SO, PLCC, QFP, electrolytic capacitors, BGA
Min. lead pitch 0.3 mm
Min. lead width 0.15 mm
Min. ball pitch 0.35 mm
Min. ball diameter 0.2 mm
Field of vision 65 mm x 50 mm
Method of illumination Front-illumination (6 levels, programmable as required)
