User Manual SIPLACE SX4/DX4 5 Working with the machine From software version SC.706.xx V ersion 06/2012 EN 5.7 Indicator lamps 259 The machine has been stopped with the STOP button; the START button must be pres sed to c…
5 Working with the machine User Manual SIPLACE SX4/DX4
5.7 Indicator lamps From software version SC.706.xx Version 06/2012 EN
258
5.7.1.2 Three color indicator lamp
Fig. 5.7 - 2 Indicator lamps for operating states (example of DX4)
L1 red indicator lamp
L2 yellow indicator lamp
L3 green indicator lamp
5.7.2 Status displays and their meanings
5
(L2)
(L1)
(L3)
Meaning Machine side Status - two color
(white/green)
Status - three color
(red/yellow/green)
The machine is producing Both sides White: --
Green: On
Red: Off
Yellow: Off
Green: On
The machine is waiting for a
board at input.
Both sides White: --
Green: 700 - 700
Red: Off
Yellow: Off
Green: 500 - 500
User Manual SIPLACE SX4/DX4 5 Working with the machine
From software version SC.706.xx Version 06/2012 EN 5.7 Indicator lamps
259
The machine has been stopped
with the STOP button; the
START button must be pressed
to continue production.
Both sides Not configured Red: Off
Yellow: Off
Green: 500 - 500
Fiducial manipulation by the
operator required.
Both sides White: --
Green: 100 - 100
Red: Off
Yellow: 500-500
Green: Off
The machine is waiting for a
recipe or is waiting for machine
preparation after receiving a
recipe.
Both sides White: --
Green: 100 - 100
Red: Off
Yellow: Off
Green: 500 - 500
The machine is preparing pro-
duction (check nozzle status,
feeder module recognition).
Both sides White: --
Green: 100 - 100
Red: Off
Yellow: Off
Green: 500 - 500
An alternative pickup position
will be used.
Respective side White: 100 -100
Green: --
Red: Off
Yellow: On
Green: On
A board needs to be taken out
of the output conveyor (e.g. for
inspection).
Respective side White: 500 -500
Green: 700 -700
Red: Off
Yellow: Off
Green: 500 - 500
The PCB conveyor is jammed
(successor machine is waiting
for boards).
Respective side White: --
Green: 700 -700
Red: Off
Yellow: Off
Green: 500 - 500
More than one pickup position
with the same components is
disabled but there is more than
one pickup position available
for use.
Respective side White: 500 -500
Green: --
Red: Off
Yellow: On
Green: On
Setup verification is required
for at least one pickup position.
Respective side White: 500 -500
Green: --
Red: Off
Yellow: 500 - 500
Green: Off
The nozzle setup is not com-
plete.
Respective side White: 500 -500
Green: --
Red: Off
Yellow: On
Green: On
The last available pickup posi-
tion is being used or there is no
pickup position left for this com-
ponent. The machine will con-
tinue to produce while there are
still other components which
can be placed.
Respective side White: 100 -200
Green: --
Red: Off
Yellow: On
Green: On
Meaning Machine side Status - two color
(white/green)
Status - three color
(red/yellow/green)
5 Working with the machine User Manual SIPLACE SX4/DX4
5.7 Indicator lamps From software version SC.706.xx Version 06/2012 EN
260
5.7.2.1 Basics
5
The filling level of the pickup
position or dipping module is
low.
Respective side White: 100 -200
Green: --
Red: Off
Yellow: On
Green: On
Unable to move one of the
boards to the next area.
Respective side White: On
Green: --
Red: Off
Yellow: 500 - 500
Green: Off
Unable to read the board bar-
code in the input conveyor. The
operator must insert the board
manually.
Respective side Not configured Red: Off
Yellow: 500 - 500
Green: Off
The machine has been auto-
matically stopped due to a non-
configured event e.g. conveyor
error
. Events which have not been
configured and which could
lead to a machine stop have not
be taken into consideration
here.
Both sides White: On
Green: Off
Red: Off
Yellow: 500 - 500
Green: Off
The production has been auto-
matically stopped (e.g. there is
no component ready for pick-
up).
Respective side White: On
Green: Off
Red: Off
Yellow: 500 - 500
Green: Off
The machine is performing a
manual function triggered by
the operator.
White: 100 -1000
Green: 700 - 700
Red: Off
Yellow: Off
Green: 500 - 500
The machine has been stopped
due to a fiducial measurement
error (e.g. board, table, feeder
module).
Both sides White: On
Green: Off
Red: Off
Yellow: 500 - 500
Green: Off
The safety loop has not closed. Respective side White: On
Green: Off
Red: On
Yellow: Off
Green: Off
Meaning Machine side Status - two color
(white/green)
Status - three color
(red/yellow/green)
Status Meaning
Off No warning and no alert
Flashes Warning, the frequency varies depending on the type of warning
On Alert
-- The described state does not affect the lamp concerned.
