2 Operational safety User Manual SIPLACE SX4/DX4 2.2 Warning labels From software version SC.706.xx Version 06/2012 EN 40 2.2.1.3 W arning label W204 2 W204 in fig. 2.2 - 1 , p age 37 and 2.2 - 2 , page 38 , and 2.2 - 3 …
User Manual SIPLACE SX4/DX4 2 Operational safety
From software version SC.706.xx Version 06/2012 EN 2.2 Warning labels
39
WARNING 2
Do not use abrasive cleaners or solvents for cleaning warning labels.
Replace any damaged or illegible warning labels.
2.2.1.1 Warning label W201
2
W201 in fig. 2.2 - 1, page 37, item no. 03009338-01 (quantity per machine: 1)
2.2.1.2 Warning label W203
2
W203 in fig. 2.2 - 1, page 37 and 2.2 - 2, page 38, item no. 03009342-01 (quantity per machine: 4)
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
SAFE OPERATION OF THE MACHINE
Safe operation of the machine depends absolutely on
the operator being familiar with the user manual and
safety instructions and putting them into effect.
2
2
2
DANGER OF CRUSHING!
Reaching in here can lead to injuries to the arms
and hands.
Do not reach into the machine while it is running
2 Operational safety User Manual SIPLACE SX4/DX4
2.2 Warning labels From software version SC.706.xx Version 06/2012 EN
40
2.2.1.3 Warning label W204
2
W204 in fig. 2.2 - 1, page 37 and 2.2 - 2, page 38, and 2.2 - 3, page 42,
Item no. 03009343-01 (quantity per machine: 8)
2.2.2 Warning label 205
Warning labels on tape cutter and used tape chute
2
W205 in fig. 2.2 - 5, page 46 and 2.2 - 6, page 47, item no. 03009344-01 (quantity per machine: 8)
2.2.2.1 Warning label W210
2
W210 in fig. 2.2 - 1, page 37 and 2.2 - 2, page 38, item no. 03009350-01 (quantity per machine: 2)
2
2
2
DANGER OF CRUSHING!
Reaching in here can lead to injuries to the arms
and hands.
Do not reach into the machine while it is running
2
2
2
2
2
2
2
2
RISK OF CUTTING!
Danger of cutting is present even when the machine is
switched off
2
2
2
2
2
2
Warning label on the EMERGENCY STOP button
