6.1.3.5 Component reject bin for the SIPLACE TwinStar
A component reject bin can be installed for the SIPLACE TwinStar. This is positioned next to the
stationary camera.
6
Fig. 6.1 - 16 Component reject bin for the SIPLACE TwinStar
6.1.3.6 Grippers and special nozzles
The SIPLACE machines can process components based on through hole technology and odd-
shaped (OSC) components, in addition to the standard SMT spectrum. ASM also continuously de-
velops special nozzles and grippers.
Special nozzles are available for all placement heads in order to process placement jobs with max-
imum speed, precision and flexibility. The use of automatic nozzle changers also reduces the
setup times that occur at a product change.
ASM can provide mechanical grippers for Pick&Place heads. If a component's surface is not suit-
able for sucking up with nozzles, then it can be picked up and placed with mechanical grippers.
There are two types of gripper and their functions can be divided into two groups:
– Grippers that grip the component at its outer edges and
– Grippers that grip the component at its inner edge.
Information on special nozzles and grippers is available from ASM. For the production of special
magazines and grippers, again contact ASM.
6 Station extensions User Manual SIPLACE SX4/DX4
6.2 DX changeover tables on the SIPLACE DX4 From software version SC.706.xx Version 06/2012 EN
314
6.2 DX changeover tables on the SIPLACE DX4
Item no. 03089820-xx DX changeover table SIPLACE DX4 with 40/2 tracks
Item no. 03089961-xx DX changeover table docking unit for 40/2 tracks
Just like the fixed DX tables, the DX changeover tables are optimized for the use of 2x8 mm SI-
PLACE tape feeder modules when using 8 mm tapes. By using 20 of these feeder modules, you
can achieve a full setup capacity of 40 8mm tracks. The design and function of the DX changeover
tables is basically identical to that of the component changeover tables for the SIPLACE SX4 ma-
chines. See “SIPLACE X series changeover table” on page 181.
6
Fig. 6.2 - 1 DX changeover table locations, SIPLACE DX4
(1) Location 1
(2) Location 2
(3) Location 3
(4) Location 4
(T) Direction of PCB transport
(1)
(4)
(2)
(3)
User Manual SIPLACE SX4/DX4 6 Station extensions
From software version SC.706.xx Version 06/2012 EN 6.2 DX changeover tables on the SIPLACE DX4
315
PLEASE NOTE:
Feeder modules can be placed on the uneven track numbers. Only these tracks are fitted with an
energy and data interface on the machine, so that the full capacity of 40 8mm tracks can be
achieved with 20 2x8mm X feeder modules. 6
CAUTION 6
The DX changeover tables may only be docked onto locations at which the DX changeover table
docking unit for the SIPLACE DX4 has been installed (fig. 5.15 - 3, page 292).
6.2.1 Safety instructions for docking the DX changeover table in or out
WARNING 6
The placement machine may only be operated if there is a DX changeover table present and
docked at each location. Fill any free locations with dummy feeder modules as described in
section 2.7.5.1, page 77.
WARNING
To prevent accidents (risk of crushing), the DX changeover table may only be docked in or out by
one person.
WARNING 6
The waste tape container must be pulled out of the DX changeover table for emptying. There is a
risk of catching your thumbs as you do so. To prevent this, observe the safety instructions in sec-
tion 5.8.2
, page 263.
CAUTION
Do not lift the DX changeover table by its handles (handles could break). 6
