User Manual SIPLACE SX4/DX4 6 Station extensions From software version SC.706.xx Version 06/2012 EN 6.2 DX changeover tables on the SIPLACE DX4 317 6.2.5 Setting up the feeder modules The optional DX changeover t able is…
6 Station extensions User Manual SIPLACE SX4/DX4
6.2 DX changeover tables on the SIPLACE DX4 From software version SC.706.xx Version 06/2012 EN
316
CAUTION
When docking and undocking, make sure that there are no body limbs in the travel area of the DX
changeover table. 6
6.2.2 Technical data
6
6.2.3 Docking the DX changeover table in or out
The optional DX changeover table is handled in the same way as the component trolley.
See “Docking the component trolley in or out” on page 289.
6.2.4 Adjusting the DX changeover table to the PCB conveyor height
The optional DX changeover table is handled in the same way as the component trolley.
See “Adjusting the component trolley to the PCB conveyor height” on page 228.
Length x width 727 mm x 592 mm
752 x 592 mm² with waste container
Height of the DX changeover table 889.5 mm for 900 mm PCB conveyor height
919.5 mm for 930 mm PCB conveyor height
939.5 mm for 950 mm PCB conveyor height
PCB conveyor height 900 mm ± 15 mm (option)
930 mm ± 15 mm (standard)
950 mm ± 15 mm (SMEMA option)
Height of handles when folded out 969 mm
Max. component feeding
(Four DX tables for SIPLACE DX4)
Location 1 and 3:
Location 2 and 4:
74 tape feeder modules, each with 2x8 mm X
40 feeder modules, each with 2x8 mm X
34 feeder modules, each with 2x8 mm X
Weight
Without feeder modules
With feeder module at all locations
80.4 kg
139.6 kg
Tape reel diameter
Standard
Maximum
Up to 432 mm (17")
483 mm (19")
User Manual SIPLACE SX4/DX4 6 Station extensions
From software version SC.706.xx Version 06/2012 EN 6.2 DX changeover tables on the SIPLACE DX4
317
6.2.5 Setting up the feeder modules
The optional DX changeover table is handled in the same way as the component trolley.
See “Setting up the feeder modules” on page 269.
6 Station extensions User Manual SIPLACE SX4/DX4
6.3 PCB barcode scanner From software version SC.706.xx Version 06/2012 EN
318
6.3 PCB barcode scanner
Item no. 00519881-xx 2D board code reader
Item no. 00519839-xx Mechanics assembly set
Item no. 00519834-xx Electrics assembly kit for 2D board code reader
Item no. 00519880-xx 1D board barcode reader
Item no. 00519838-xx Mechanics assembly set
Item no. 00519833-xx Electrics assembly kit for 1D board barcode reader
6.3.1 Description
The PCB barcode reader is used to automatically record and decode barcodes on PCBs. The
PCB barcode scanners are installed on a special frame on the input side of the placement ma-
chine on the PCB
conveyor. Depending
on the position of the barcode strips, the barcode scanner can be attached in a few simple
steps so that the strips can be read parallel to or across the PCB transport direction.
When using dual conveyors, four board barcode readers can be retrofitted. These can scan both
the top or bottom of the boards on both conveyor lanes.
There are two variants of the barcode scanner:
– 1D board barcode readers
This barcode scanner processes barcodes. 6
– 2D board code reader
This code reader processes barcodes and matrix codes. Matrix code is primarily used when
there is
not enough space for barcode labels. 6
PLEASE NOTE:
A combination of 1D and 2D barcode reader and the 2D code reader in the same machine is not
possible. 6
