User Manual SIPLACE SX4/DX4 1 Introduction From software version SC.706.xx Version 06/2012 EN 1.1 SIPLACE SX4 17 Three placement me thods are possible for pr ocessing the components: – Collect&Place, – Pick&Place…
1 Introduction User Manual SIPLACE SX4/DX4
1.1 SIPLACE SX4 From software version SC.706.xx Version 06/2012 EN
16
1.1 SIPLACE SX4
1
Fig. 1.1 - 1 SIPLACE SX4 placement machine
The SIPLACE SX4 placement machine has the following distinguishing features:
– High precision,
– High configuration flexibility,
– Head and gantry modularity
– Placement performance up to the high end process range and
– A wide ranging component spectrum from 01005 components to a size of
110 mm x 10 mm.
User Manual SIPLACE SX4/DX4 1 Introduction
From software version SC.706.xx Version 06/2012 EN 1.1 SIPLACE SX4
17
Three placement methods are possible for processing the components:
– Collect&Place,
– Pick&Place and
– A combination of Collect&Place and Pick&Place (mixed mode).
The SIPLACE SX4 placement machine has four gantries. The head modularity principle devel-
oped by SIPLACE allows you to change placement heads quickly and easily. For an overview of
the placement head configuration, refer to section 1.1.1
from page 17.
These can be quickly and accurately positioned by linear motors, moving independently of one
another in the X and Y directions.
There are four locations available for supplying components. These can be fitted with component
trolleys and configured with up to 40 tracks.
1.1.1 Overview of placement head configuration
1
CPP_H = Multistar CPP in high assembly position
Placement area 1 Placement area 2
C&P20 / C&P20 C&P20 / C&P20
C&P20 / C&P20 CPP / CPP
C&P20 / C&P20 TH / TH
C&P20 / C&P20 CPP_H/TH
CPP / CPP CPP / CPP
CPP / CPP CPP_H/TH
CPP / CPP TH / TH
1 Introduction User Manual SIPLACE SX4/DX4
1.2 SIPLACE DX4 From software version SC.706.xx Version 06/2012 EN
18
1.2 SIPLACE DX4
1
Fig. 1.2 - 1 SIPLACE DX4 placement machine
The SIPLACE DX4 placement machine has the following distinguishing features:
– High precision,
– Intelligent placement optimization,
– Intelligent configuration strategies,
– Placement performance up to the high end process range
The Collect&Place procedure is used for processing the components.
The SIPLACE DX4 placement machine has four gantries. These can be quickly and accurately
positioned by linear motors, moving independently of one another in the X and Y directions.
There are four locations with DX tables available for supplying components. These can be config-
ured with up to 40 tracks.
