SIPLACE Pro Feature Description Ausgabe 05/2014 Edition
60
5 Feature Description SIPLACE Pro V7.xx
New and modified Machine Support (V7.0)
5.1 New Machine Type SIPLACE SX
SIPLACE Pro 7.0 supports the new machine type SIPLACE SX. The SIPLACE SX can be
configured with one or two gantries (gantry modularity).
In the station editor you define if the SIPLACE SX is equipped with one or two gantries at the
factory. You can change this configuration in the setup editor.
For detailed descriptions and possible configurations, please refer to the relevant SIPLACE SX
documents.
5.1.1 New Hardware Options
Es stehen neue Hardware Optionen für die Konfiguration der SIPLACE SX zur Verfügung.
Object type Term Description
Table type
Change Over Table 60 X Component changeover table for
SIPLACE SX machines with 60 tracks.
This table can be placed at the inner and
the outer position of the SIPLACE SX.
Table WPC 60 X Table for setting up the WPC5 at the
SIPLACE SX.
Conveyor type
Single Conveyor SX Single conveyor at the SIPLACE SX.
Dual Conveyor SX Dual conveyor at the SIPLACE SX.
5.1.2 Heavy PCB
The PCB conveyor of the SIPLACE SX allows the transport of heavy PCBs.
● For single conveyor (assembled PCBs of 2 to 5 kg)
● For dual conveyor (assembled PCBs of 1 to 2 kg)
For detailed information, please refer to the online help in SIPLACE Pro Desk.
SIPLACE Pro Feature Description Ausgabe 05/2014 Edition
61
5.2 Support of 2x8mm X Feeders
SIPLACE Pro 7.0 supports the new 2x8mm X-Feeder type for machines of the X series, X4i and
SX. This feeder is equipped with two component divisions in 8 mm tapes. The 2x8mm X feeder can
be used for 0201 component shapes but not for 01005 shapes.
For a detailed description, please refer to the relevant documents.
5.3 Support of the IPTE Multi Stick Feeder
SIPLACE Pro 7.0 supports the new IPTE MSF 60 and IPTE MSF XL80 feeder type for machines of
the X series and SX1,SX2. The feeders can be placed on the X table types COT 40 and COT 40.
5.4 Support of the Multistar CPP Placement Head
The Multistar CPP head (Collect&Pick&Place) has the ability to work in three different placement
modes.
● Small components can be placed in the Collect&Place mode.
● Small to medium components can be placed in the mixed mode.
● Medium components and one large component (in the 6 o' clock position) can be placed in the
Pick&Place mode.
The Multistar CPP head can be installed in two different positions (high and low position). In the
high position components with a height of up to 11.5 mm can be placed.
SIPLACE Pro Feature Description Ausgabe 05/2014 Edition
62
5.4.1 New Hardware Components in the Setup Editor
Object type Name Description
Head type CPP 12 2xxx CPP-Head with 12 segments
Nozzle Changer
NC CPP 20xx 2x3 Nozzle changer for X-series machines
for nozzle series 20xx.
NC CPP 20xx28xx 2x3 Nozzle changer for X-series machines
for nozzle series 20xx und 28xx.
NC CPP 20xx 2x2 Nozzle changer for X4i on location 2 and
4 for nozzle series 20xx.
NC CPP 20xx28xx 2x2 Nozzle changer for X4i on location 2 and
4 for nozzle series 20xx and 28xx.
NC PP 20xx 4 Nozzle changer for SX-series machines.
With 4 magazines for nozzle series 20xx.
NC CPP 20xx28xx 4 Nozzle changer for SX-series machines.
With 4 magazines for nozzle series 20xx
and 28xx.
Nozzle Magazine
CPP12 20xx Nozzle magazine with 12 pockets for
nozzle series 20xx.
CPP 9 28xx Nozzle magazine with 9 pockets for
nozzle series 28xx.
5.5 Support of Station Software 703.xx
SIPLACE Pro 7.0 supports the station software 703.xx on the machine types X2, X3, X4, X4i and
SX.
The station software 703 includes all functions of the station software 702.xx.
That means that the following basic functions are supported:
● SIPLACE SX
● Waffle pack changer, type WPC5
● An alternative camera position for SIPLACE X4i
● 2x8mm X feeders
