7.2 New Components (V9.2)
Object Type Name Description
Head C&P 12 3xxx New Revolver Head 12 (DLM4) for the station
types DX1, DX2
Evaluation
systems
RV Camera X (28) 24.2x24.2
RV Camera X (29) 32x32
RV Camera (30) 32x32
For the Revolver Head 12 (DLM4)
C&P 12 3xxx on DX1, DX2
RV Camera (30) 32x32
NOTICE
The "RV Camera (30) 32x32" camera is the new standard camera for the CPP
head.
By means of the "Component Shape and Fiducial Upgrade Tool" the camera 30 can
be added in all component shapes for which the camera 29 is entered as camera.
All existing Vision data of the previous standard camera will be kept.
3D Coplan Sensor For X2, X3, X4, SX1 and SX2
Nozzles Nozzle Series 3xxx Nozzles for DLM 4 C&P head, analog to 9xx
nozzles. Numbers:
● 3070-3099
● 3500-3799
● 3870-3999
Extended custom nozzles for
Twin Head
Numbers (from station software version 605.03
and 705, no prior versions):
● 5500-5999
Extended custom nozzles for CPP Numbers (from station software version 605.03
and 705, no prior versions):
● 2500-2799 (20xx)
● 2900-2999 (28xx)
NOTICE
The extended custom nozzles can be activated in SIPLACE Pro Desk in the Tools /
Settings / Global Settings menu.
CAUTION
The "Extended custom nozzles" feature compulsively requires that all placement
machines are operated with the station software versions 605.03 and 705.
Prior station software versions do not support these extended custom nozzles.
Using this feature with prior station software versions will result in undefined states.
Nozzle
changers
NC C&P 12 3xxx 4
NC C&P 12 3xxx 2 2
NC C&P 12 3xxx 2 3
For 3xxx nozzles
Nozzle C&P 12 3xxx For 3xxx nozzle changers
SIPLACE Pro Feature Description Ausgabe 05/2014 Edition
80
Object Type Name Description
changer
magazine type
Feeders 4mm X Feeder
16mm XN Feeder
For all machines of the DX, SX- and X series
Surftape Feeder AX The Component Shape and Fiducial Upgrade
tool can enter the Surftape Feeder AX in all
component shapes for which a Surftape
Feeder (8mm ST, 12mm ST or 16mm ST) has
been entered.
7.3 Further Features (V9.2)
7.3.1 Station Software 705
SIPLACE Pro 9.3 supports version 705 for the:
● DX series: DX1, DX2 and DX4
● SX series: SX1, SX2 and SX4
● X series: X2, X3, X4, X4i, X4T and X4iT
7.3.2 Automatic Width Adjustment
On stations from station software 704, SIPLACE Pro supports the automatic width adjustment.
The station software offers a manual width adjustment via its user interface.
7.3.3 Refined Time Model for SOKO Nozzles
Depending on the station software version 703, 704 or 705 a refined optimization time model is
used to exactly simulate overlapping axis travelling diagrams.
7.3.4 Option Long Board for DX4 and SX4
From station software 705, long boards can be optimized and produced using the reverse stepping
feature.
7.3.5 01005 Support for 2x8mmX
From station software 605 and 705, the 01005 placement process is supported without any
restrictions.
SIPLACE Pro Feature Description Ausgabe 05/2014 Edition
81
7.3.6 PCB Barcode Recognition by Means of the PCB Camera
From station software 705, PCB and panel barcodes can be read by means of the PCB camera
(Traceability data).
The barcode scanned at the first station of the line can be passed on to the next placement
machine. Passing on read barcode data is only supported if the placement machines are standing
in direct succession and are not separated e.g. by an inspection conveyor belt.
The barcode data can be described as a barcode fiducial and assigned in the PCB editor. Barcode
fiducials can be scanned on the placement machine and saved as barcode fiducials in SIPLACE
Pro.
NOTICE
The feature is activated with the "Reading Barcode with PCB Camera" license.
7.3.7 Alternative Components
From station software 705: In the PCB editor, one or more alternative components can be defined
for each placement position in addition to the default component. Thus, it is possible to describe for
one PCB:
● Components of different manufacturers or / and
● Components with differing component shapes or / and
● Components with different packaging forms and feeders.
The optimization checks the necessary technical constraints such as common nozzle, common
camera, and same feeder class and calculates the number of possible alternatives.
The default component is set up by the optimization within the SIPLACE Pro setup. The possible
alternatives can be shown using the Recipe Analyzer and the Setup report.
The download sends recipes with alternative components, if this feature is activated on all stations
in the line and if a license is present for each station.
As long as the feature is not activated on all stations in the line or not supported by all software
versions in the line, the recipe is sent without alternative component data, i.e., a mixed operation
within a line is not possible.
NOTICE
1. The feature requires the "Forced Setup Verification" operation mode. The use of
splice sensors is highly recommended, if alternative components will directly be
spliced directly.
2. The feature is activated with the "Alternative Components" license.
3. For further information on this feature and its restrictions please see the user manual
"Alternative Components" on the product CD.
4. The SiCluster Professional option supports alternative components.
