SIPLACE Pro Feature Description Ausgabe 05/2014 Edition
78
7 Feature Description SIPLACE Pro V9.xx
NOTICE
The SIPLACE Pro 9.0 and 9.1 versions have not been released.
7.1 New Stations and Tables (V9.2)
Object Type Name Description
Station types CA3
CA4
New Chip Assembly with SIPLACE Wafer
System (SWS)
DX1
DX2
DX4
One gantry
Two gantries
Two working areas with two gantries
each, equipped with a single or dual
conveyor.
X4T
X4iT
Placement machine X4 or X4i with
overwidth dual conveyor
Table types DX Table 34 X Fixed table with 34 tracks, start track
always uneven (1, 3, 5, …)
DX Table WPC 60 X Fixed table for WPC
DX Table 40 X Fixed table with 40 tracks, can also be
used for LED placement on station type
X4, start track always uneven (1, 3, 5, …)
DX Table 60 X Fixed table with 60 tracks, start track
always uneven (1, 3, 5, …)
DX Change Over Table 34 X Changeover table with 34 tracks, start
track always uneven (1, 3, 5, …)
DX Change Over Table WPC 60 X Changeover table for WPC
DX Change Over Table 40 X Changeover table with 40 tracks, can also
be used for LED placement on station
type X4, start track always uneven (1, 3,
5, …)
DX Change Over Table 60 X Changeover table with 60 tracks, start
track always uneven (1, 3, 5, …)
SIPLACE Pro Feature Description Ausgabe 05/2014 Edition
79
7.2 New Components (V9.2)
Object Type Name Description
Head C&P 12 3xxx New Revolver Head 12 (DLM4) for the station
types DX1, DX2
Evaluation
systems
RV Camera X (28) 24.2x24.2
RV Camera X (29) 32x32
RV Camera (30) 32x32
For the Revolver Head 12 (DLM4)
C&P 12 3xxx on DX1, DX2
RV Camera (30) 32x32
NOTICE
The "RV Camera (30) 32x32" camera is the new standard camera for the CPP
head.
By means of the "Component Shape and Fiducial Upgrade Tool" the camera 30 can
be added in all component shapes for which the camera 29 is entered as camera.
All existing Vision data of the previous standard camera will be kept.
3D Coplan Sensor For X2, X3, X4, SX1 and SX2
Nozzles Nozzle Series 3xxx Nozzles for DLM 4 C&P head, analog to 9xx
nozzles. Numbers:
● 3070-3099
● 3500-3799
● 3870-3999
Extended custom nozzles for
Twin Head
Numbers (from station software version 605.03
and 705, no prior versions):
● 5500-5999
Extended custom nozzles for CPP Numbers (from station software version 605.03
and 705, no prior versions):
● 2500-2799 (20xx)
● 2900-2999 (28xx)
NOTICE
The extended custom nozzles can be activated in SIPLACE Pro Desk in the Tools /
Settings / Global Settings menu.
CAUTION
The "Extended custom nozzles" feature compulsively requires that all placement
machines are operated with the station software versions 605.03 and 705.
Prior station software versions do not support these extended custom nozzles.
Using this feature with prior station software versions will result in undefined states.
Nozzle
changers
NC C&P 12 3xxx 4
NC C&P 12 3xxx 2 2
NC C&P 12 3xxx 2 3
For 3xxx nozzles
Nozzle C&P 12 3xxx For 3xxx nozzle changers
SIPLACE Pro Feature Description Ausgabe 05/2014 Edition
80
Object Type Name Description
changer
magazine type
Feeders 4mm X Feeder
16mm XN Feeder
For all machines of the DX, SX- and X series
Surftape Feeder AX The Component Shape and Fiducial Upgrade
tool can enter the Surftape Feeder AX in all
component shapes for which a Surftape
Feeder (8mm ST, 12mm ST or 16mm ST) has
been entered.
7.3 Further Features (V9.2)
7.3.1 Station Software 705
SIPLACE Pro 9.3 supports version 705 for the:
● DX series: DX1, DX2 and DX4
● SX series: SX1, SX2 and SX4
● X series: X2, X3, X4, X4i, X4T and X4iT
7.3.2 Automatic Width Adjustment
On stations from station software 704, SIPLACE Pro supports the automatic width adjustment.
The station software offers a manual width adjustment via its user interface.
7.3.3 Refined Time Model for SOKO Nozzles
Depending on the station software version 703, 704 or 705 a refined optimization time model is
used to exactly simulate overlapping axis travelling diagrams.
7.3.4 Option Long Board for DX4 and SX4
From station software 705, long boards can be optimized and produced using the reverse stepping
feature.
7.3.5 01005 Support for 2x8mmX
From station software 605 and 705, the 01005 placement process is supported without any
restrictions.
