SIPLACE Pro Feature Description Ausgabe 05/2014 Edition

7.3.8 SIPLACE Random Setup

Up to now feeders and components have to be set up exactly on the tracks that have been

calculated by the optimization and assigned by the download.

The SIPLACE Random Setup feature offers the opportunity to set up components on another track

of the same table or even to set up another table in the line. This is only supported for X feeders.

Other feeder types must be set up on the accurate track as described in the setup.

It is not possible changing the setup for a production in process.

Procedure:

1. Create an optimized target setup using the optimization.

2. In the LineControl GUI the "Random Setup" function is enabled in the production plan.

3. A recipe or job with an optimized setup is added to the production plan.

4. Typically, the required components have already been set up on the X feeders in the pre-setup.

5. The pre-setup-up X feeders are placed on the tables of the line. It is recommended to position

the feeders as accurate as possible with respect to the track of the optimization result.

NOTICE

Deviations of the real setup compared with the target setup leads may lead to deviations

of real and simulated production time and thus to an unequal utilization within the line.

6. During the download of the recipe to the line, LineControl creates a working copy of the

optimized target setup. Setup Center detects the feeders actually set-up at the station and

enters them into the working copy.

NOTICE

The computer on which the Setup Center application is installed can be selected in the

configuration of the Line Control GUI.

7. LineControl checks if all components of the PCB(s) of the recipe are correctly entered in the

working copy of the setup according to the download settings. If components are missing, they

can be added on their standard X feeder from the optimized setup.

8. The job is sent to the station after a successful integrity and license check.

NOTICE

The feature requires station software 705. Earlier software versions (605 or 703) were

not tested.

The features "Random Setup" and "Alternative Component" cannot

be combined on one

single line.

For further information on this feature and its restrictions please see the user manual

"SIPLACE Random Setup" on the product CD.

SIPLACE Pro Feature Description Ausgabe 05/2014 Edition

7.3.9 Teaching of Placement Positions

From station software 705, placement position offsets (X, Y and angle) can be taught at the station

and uploaded to SIPLACE Pro.

In the PCB editor, the placement positions to be taught have to be marked. The taught placement

position offsets are taken into account when supplying data to stations with prior software versions

(e.g. station software version 40x and 50x). A change in the placement position offsets is

distributed to other stations in the line that place the placement position of the same name.

NOTICE

The SIPLACE Pro user "Service" has to have writing access to placement lists.

In addition, the user logged into the station has to have writing access to the placement

list that contains the uploaded placement position.

7.3.10 Split Table at Track and SiCluster Professional

Besides optimizing split tables in SiCluster Professional it is also possible to use this option for the

cluster jobs and their Result Jobs.

7.3.11 Whispering of Barcode Information

NOTICE

The feature can be activated with the "Whispering of Barcodes" license.

7.3.12 Long Board Option

NOTICE

The feature can be activated with the "Long Board Option" license.

7.3.13 Integrity Check for Multiple Jobs

Similar to the Multi Job Optimization and the Multi Cluster Job Optimization there is the Multi

Integrity Check in the Optimizer toolkit. From the structure tree of the recipes the recipes to be

checked are added to a recipe list and optimized in the desired sequence and according to the

settings.

At the same time, the optimization starts an adjustable number of processes and thus utilizes the

present multi core processors.

7.3.14 Query Tool

The underlined results of queries can be clicked on. The corresponding object is opened in

SIPLACE Pro Desk.

SIPLACE Pro Feature Description Ausgabe 05/2014 Edition

7.3.15 Nozzle Report

Using the Nozzle reports, it is possible to create a documentation of a single nozzle and a list of

nozzles.

In the list of several nozzles up to ten attributes can be selected. The nozzle attributes to be shown

can be changed in the report details.

The report can be started via the context menu in the structure view.

7.3.16 Warnings as Errors

All warning messages of the Optimizer can be upgraded to an error or downgraded to a warning

again.

7.4 New functions (V9.3)

7.4.1 SIPLACE Pro LED Pairing

SIPLACE Pro LED Pairing supports the programming process when using LEDs in electronic

assemblies. The LEDs to be used can often have different brightness classes. To achieve

homogenous brightness, these differences need to be compensated by fitting adjusted series

resistors in the circuits. On the software side, the compatible types need to be defined in the board

and optimized setup.

The LED Pairing tool supports description of these types in three individual steps:

1. Import and assignment of LED matrix files (LRX files), each placement list can have an LED

matrix file assigned to it.

2. Prepare: generate and optimize the job, recipe and setup templates, based on previously

optimized reference jobs and the assigned LED matrix file.

3. Produce: select the available LED brightness classes on the basis of the LED matrix file, then

automatic generate the recipes and setups used for production, on the basis of a recipe

template (for recipe changeover) or a real recipe (for new definition after change to another

LED brightness class).

The SIPLACE Pro LED Pairing tool is a licensed Windows application, which can also be started

from SIPLACE Pro Desk.

The LED matrix file format is described in the Online Help.

7.4.2 Improved sequence of nozzles on the head

The "Random Setup" feature (available since SIPLACE Pro 9.2) enables you to configure

components on another track of the same table or on another table in the line.

During the integrity check, SIPLACE Pro 9.3 optimizes the sequence of nozzles on the head. The

aim is to minimize the travel distances in accordance with the actual setup. This procedure also

has a beneficial effect on conventional optimization.

7.4.3 Improved user guidance for EDM Difference Editor

The comparison of two component shapes with line-specific Vision data in the SIPLACE EDM

Difference Editor has been improved. When applying modified data from the clearing pool to the

master data bank, any differences are now shown more clearly.
