SIPLACE Pro Feature Description Ausgabe 05/2014 Edition

5.4.1 New Hardware Components in the Setup Editor

Object type Name Description

Head type CPP 12 2xxx CPP-Head with 12 segments

Nozzle Changer

NC CPP 20xx 2x3 Nozzle changer for X-series machines

for nozzle series 20xx.

NC CPP 20xx28xx 2x3 Nozzle changer for X-series machines

for nozzle series 20xx und 28xx.

NC CPP 20xx 2x2 Nozzle changer for X4i on location 2 and

4 for nozzle series 20xx.

NC CPP 20xx28xx 2x2 Nozzle changer for X4i on location 2 and

4 for nozzle series 20xx and 28xx.

NC PP 20xx 4 Nozzle changer for SX-series machines.

With 4 magazines for nozzle series 20xx.

NC CPP 20xx28xx 4 Nozzle changer for SX-series machines.

With 4 magazines for nozzle series 20xx

and 28xx.

Nozzle Magazine

CPP12 20xx Nozzle magazine with 12 pockets for

nozzle series 20xx.

CPP 9 28xx Nozzle magazine with 9 pockets for

nozzle series 28xx.

5.5 Support of Station Software 703.xx

SIPLACE Pro 7.0 supports the station software 703.xx on the machine types X2, X3, X4, X4i and

SX.

The station software 703 includes all functions of the station software 702.xx.

That means that the following basic functions are supported:

● SIPLACE SX

● Waffle pack changer, type WPC5

● An alternative camera position for SIPLACE X4i

● 2x8mm X feeders

SIPLACE Pro Feature Description Ausgabe 05/2014 Edition

5.5.1 Overview of the Component Supply

Station software 703.xx supports the following new feeder types.

Feeder type Name

Waffle pack changer

WPC5

Linear feeder with adapter on

X table

IPTE MSF 60 AX

IPTE MSF XL80 AX

5.5.2 New Nozzles

The following new nozzles are available for the CPP head.

Nozzle series Name

20xx

2028 CPP

2057 CPP

5.5.3 New Nozzle Changers

The following new nozzle changers are available for the C&P 20 head and the Twin Head.

Nozzle changer Namr

C&P20 10xx 4 Nozzle changer for the C&P20

head with 4 magazines for the

nozzle series 10xx.

NC Twin Flexible 8 Nozzle changer for the Twin

Head with up to 8 magazines

for the nozzle series 5xx.

5.6 Support of WPC5

SIPLACE Pro 7.0 supports the new waffle pack changer type WPC5. The WPC5 has got 28 levels

for waffle packs and can be used on SIPLACE SX machines. For detailed descriptions and

possible configurations, please refer to the relevant SIPLACE SX documents.

SIPLACE Pro Feature Description Ausgabe 05/2014 Edition

New and modified Functions (V7.0)

5.7 Setting the Specific Feeder Pitch

In the component and the component shape editor it is now possible to set a feeder specific value

for the Feeder Pitch. That means that the Feeder Pitch for component shape or component can

be set differently for each assigned feeder. In addition, the Feeder Pitch can now be changed in

the setup without having to change the values in the component editor or the component shape

editor.

5.8 Generating Recipe Analyzer Data during Download (Option)

A separate license is required in order to use this function. It is possible in SIPLACE Pro 7.0 to

have the recipe analysis generate data automatically while the recipe is being sent to the station

(download). This data is generated in XML format and can be provided in a shared directory.

The network share is configured in LCGUI.

This data can then e. g. be processed and evaluated by an external application.

For a detailed description of the data structure please refer to the "Interface Description - Recipe

Analyzer API" document with the item no. [00196138-xx].
