SIPLACE Pro Feature Description Ausgabe 05/2014 Edition

5.21 Restricting the Amount of Data during Import /Export of XML

Files

You can change the default setting of 50 MByte under the Tools => Settings => General settings

tab.

5.22 Optimizing of Standard and Long Boards

If, in one setup, normal PCBs were produced with the "Long board" option, problems during

optimization could occur. It is now possible, to optimize long and normal PCBs together in the

same initial setup. The "Long board" option can now be enabled for normal PCBs.

5.23 Determining the Load Factor of the Placement Areas During

Optimization

During optimization, the calculation of the placement content in the placement heads can be

influenced by the Load Factor. This means, that the optimization will distribute more or fewer

placements to the respective placement heads in the placement area.

You can enter the Load Factor in the Setup Editor => Location => Simulation tab.

5.24 Improving the Usability of SIPLACE Pro Desk

5.24.1 Deleting Directories in the Tree Structure

If a directory is deleted using this function, all objects in all subdirectories are deleted, too. There is

the possibility to delete only those objects and their subdirectories that are no longer used.

SIPLACE Pro Feature Description Ausgabe 05/2014 Edition

New and Modified Functions (V7.1 SP1)

5.25 Improving the Usability

5.25.1 Assigning Alternative Feeders in the Table Editor

If alternative feeders are entered in the component shape or the component, these are displayed in

the context menu of the table list and can be newly assigned there. If the alternative feeder cannot

be set up on the table (e. g. for there is not enough space), this feeder is copied into the clipboard.

The user can change the table assignment manually and put the feeder from the clipbaord onto the

table later on.

5.25.2 Show Non Collision Nozzles Types

The Precedence Finder now shows Non Collision Nozzles Types.

5.25.3 Replace of Nozzles

Using the Component Shape and Fiducial Upgrade Tool one can replace assigned nozzles for all

of the existing component shapes.

5.25.4 Stationwise Download

The function stationwise download is now supported for station software from 703.xx onward.

5.26 Identical Nozzle Changer Configuration

In SiCluster Professional it is optionally possible to create an identical nozzle changer configuration

for all setups. In the previous version this was only possible for constant tables using the runtime

intensive option for re-optimizing constant tables.

5.27 Multi-Clusterjob-Optimizer

The Multi-Clusterjob-Optimizer is an efficient tool with which you can process cluster jobs in batch

mode. The single cluster jobs get inserted into the cluster job list from the cluster job tree and can

be optimized in the desired order.

SIPLACE Pro Feature Description Ausgabe 05/2014 Edition

6 Feature Description SIPLACE Pro V8.xx

6.1 New Machine SIPLACE SX4

Object type Name Description

Station type SX4 The SIPLACE SX4 offers two gantry configuration

options: "High speed" with inner table positions and

"Flexible" with outer table positions in the second

working area.

Conveyor type Dual Conveyor SX4 Dual conveyor at the SIPLACE SX4

Quad Conveyor SX4 Quad conveyor at the SIPLACE SX4

6.2 Further New Components

Object type Name Description

Camera C&P 20 Camera CA (41)

8.9 x 8.9

For the X2, X3, X4, X4i, SX1/2, SX4 stations with

station software version 704

Software version

of the vision

SIPLACE Vision V41 For stations with station software version 605

SIPLACE Vision V42 For stations with station software version 704

Waffle pack

changer

WPC6 Like the WPC5 the WPC6 has 28 levels for trays. It

can, however, be refilled without stopping the

station.

From station software version 704 on the WPC 60

X table.

X feeder

DATA I/O Road Runner, Road Runner XLF

IPTE Multi Stick Feeder: IPTE MSF 60 AX und IPTE MSF

XL80 AX
