( S t a t i o n ) 2 0 1 0 2020 2 0 3 0 2 0 4 0 (Type of components) Mecha Vision Lase r Laser Vision Square chip OK OK OK OK MELF OK OK OK OK Aluminum electrolytic capacitor OK OK OK OK OK OK GaAsFET OK OK OK OK OK OK SO…
J league socket OK OK OK OK OK OK OK OK OK
Gull wing socket OK OK OK OK OK OK OK OK OK
Socket with bumper OK OK OK OK OK OK OK OK
outline recog. OK
General vision
component
Other components OK OK OK OK OK OK
(Station) 2010 2020 2030 2040
(Type of
components)
Mecha Vision Laser Laser Vision
Square chip OK OK OK OK
MELF OK OK OK OK
Aluminum
electrolytic capacitor
OK OK OK OK OK OK
GaAsFET OK OK OK OK OK OK
SOT OK OK OK OK OK
SOP OK OK OK OK OK OK
HSOP OK OK OK OK OK OK
SOJ OK OK OK OK OK OK
QFP OK OK OK OK OK OK
QFJ(PLCC) OK OK OK OK OK OK
BQFP(PQFP) OK OK OK OK OK OK
TSOP OK OK OK OK OK OK
TSOP2 OK OK OK OK OK OK
BGA OK OK OK OK OK OK
FBGA OK OK
Net work resistant OK OK OK OK
Trimmer OK OK OK OK
One way lead
connector
OK OK OK OK OK OK
Two way lead
connector
OK OK OK OK OK OK
Z lead connector OK OK OK OK OK
CON OK OK
J league socket OK OK OK OK OK OK
Gull wing socket OK OK OK OK OK OK
Socket with bumper OK OK OK OK OK OK
Outline recog. OK OK
General vision
component
OK OK
Other components OK OK OK OK
[Deal]
Rearrange the combination referring to the above table.
E3861 The designated station does not support directed component size and height.
[Cause]
Appears if any invalid value is specified for a particular model; the following table lists the part
outside dimension and height available for each station:
(Specified station) (Part outside dimension)
(Height)
710 0.5mm-20.0mm 0.0mm- 6.0mm
720 Mechanical 0.5mm-33.5mm 0.0mm-10.0mmVision
Standard VCS 7.0mm-50.0mm 0.0mm-10.0mmVCS03
7.0mm-33.5mm 0.0mm-10.0mm730 Laser 0.5mm-23.5mm
*0.0mm- 6.0mm(PLUS) Laser LAHD 0.5mm-23.5mm
*0.0mm- 6.0mm
LA 0.5mm-33.5mm
*0.0mm- 6.0mm740 Vision Standard VCS 3.0mm-50.0mm
*0.0mm-10.0mmVCS03 3.0mm-33.5mm
*0.0mm-10.0mm
Laser 0.5mm-33.5mm
*0.0mm-10.0mm750 Laser 0.5mm-23.5mm
*0.0mm- 6.0mm
760 Vision Standard VCS 3.0mm-50.0mm
*0.0mm-10.0mm
VCS03 (Optional VCS 37.5mm) 3.0mm-33.5mm
*0.0mm-10.0mm
Optional VCS 27.5mm 4.0mm-24.0mm
*0.0mm-10.0mm
Laser 0.5mm-33.5mm
*0.0mm-10.5mm
*: For a station equipped with the function for processing 20mm component, 0.0mm to 20.00mm2010 Laser
0.3mm-26.0mm 0.0 mm ?6.0 mm (up to 20.0 mm for machines compatible with 20 mm)
2020 Laser 0.3mm-50.0mm 0.0 mm ?12 mm (up to 20.0 mm for machines
compatible with 20 mm)
2030 Laser 0.3mm-26.0mm 0.0mm-6.0mm
2040 Laser 0.3mm-50.0mm 0.0mm-25.0mm
[Deal]
For available dimensions, refer to the above table.
