Copyright © ViT rox All Rights Reserved . 329 ROI List Component View Inspection Result Algorithm parameters *ROI : Region of inspection Editor T ools
Copyright © ViTrox All Rights Reserved.
328
Algorithm Editor
Designed to inspect and fine tune the algorithm to prevent false call & escapee.
Copyright © ViTrox All Rights Reserved.
329
ROI ListComponent View
Inspection Result
Algorithm parameters
*ROI : Region of inspection
Editor Tools
Copyright © ViTrox All Rights Reserved.
330
1. User require fine tune the algorithm by adjusting the parameters.
*Refer the CR, B, S & U Training Slide for each of the parameters explanation.
2. User can drag to resize the ROI boxes size at the component view interface.
3. After fine tuned the parameters, user can press on “Inspect” button to verify the inspection result. The
inspection results can be view on the bottom side.
