Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 3 Technical data and assemblies
From software version SC.713.1 Edition 12/2020 3.2 Performance data for the SIPLACE SX1/SX2 V2
105
3.2 Performance data for the SIPLACE SX1/SX2 V2
3.2.1 Machine performance
3
Placement head types SIPLACE SpeedStar (C&P20 P)
SIPLACE MultiStar (CPP)
SIPLACE TwinStar (TH)
Placement performance
The placement performance is influenced by the different head combinations and head positions, plus the conveyor
configurations. Individual options and customized applications also influence the placement performance. On
request, ASM can calculate the actual performance of your product on your machine configuration.
IPC value [components/h]
According to the vendor-neutral conditions of the IPC 9850 standard published by the Association of Connecting
Electronics Industries.
SIPLACE benchmark value [components/h]
The SIPLACE benchmark value is measured during the machine acceptance tests. It corresponds to the conditions
set out in the ASM scope of service and supply.
SIPLACE SX2 placement
machine
Placement area IPC value Benchmark value
C&P20 P / C&P20 P 59,000 74,000
C&P20 P / CPP
*a
48,000 60,000
CPP
b
/ CPP
b
38,000 46,000
*b
CPP / TH 23,100 27,000
TH / TH 10,200 11,000
SIPLACE SX1 placement
machine
Placement area IPC value Benchmark value
C&P20 P 29,500 37,000
CPP
a
19,000 23,000
TH 5,100 5,500
*)a MultiStar CPP: low installation position
*)b MultiStar CPP: high installation position
3 Technical data and assemblies Instruction manual SIPLACE SX1/SX2 Edition V2 and V3
3.2 Performance data for the SIPLACE SX1/SX2 V2 From software version SC.713.1 Edition 12/2020
106
3.2.2 PCB conveyor - data
3
Single conveyor Flexible dual con-
veyor
Dual conveyor in single
conveyor mode
Standard dimensions
(length x width)
50 mm x 50 mm to
450 mm x 560 mm
50 mm x 50 mm to
450 mm x 260 mm
50 mm x 50 mm to
450 mm x 460 mm
Dimensions with “Long
Board”option
(length x width)
50 mm x 50 mm to
1525 mm
*a
x 560 mm
50 mm x 50 mm to
850 mm x 260 mm
50 mm x 50 mm to
850 mm x 460 mm
Stationary conveyor side Right, left or outer
Automatic electrical width adjust-
ment
Standard
PCB thickness
Standard
"Thick board" option
0.3 mm to 4.5 mm
2.0 mm to 6.5 mm
Clamping length of board 450 mm
Space for positioning support pins 440 mm
PCB warpage See page 151
PCB weight
*b
Standard Max. 3.0 kg Max. 2.0 kg Max. 2.0 kg
Clearance on PCB underside 25 mm
PCB conveyor height
Option
Standard
Option SMEMA
900 mm
930 mm
950 mm
Type of interface SMEMA or IPC-HERMES-9852
Component-free PCB handling
edge
3 mm
PCB changeover time
Single conveyor
Dual conveyor
*c
< 1.5 seconds
0 seconds
*)a With input/output conveyor only
*)b The board weight value refers to the weight of the board plus the weight of the components.
*)c 0 seconds in asynchronous mode, otherwise 1.5 seconds.
Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 3 Technical data and assemblies
From software version SC.713.1 Edition 12/2020 3.3 Component feeding
107
3.3 Component feeding
3
3.4 Ambient conditions and connection values
3.4.1 Ambient conditions for packaging, transportation and storage
3
3.4.2 Ambient conditions for placement machine operation
3
Feeder locations
2 component trolleys with 60 tracks
2 component trolleys with 30 tracks
120 feeders with 8 mm each
60 feeders with 8 mm
Technical data
Tape reel diameter 178 mm to max. 483 mm diameter (7" - 19")
Component trolley changeover time < 1 minute
Temperature range Between -25°C and 55°C
Atmospheric humidity Up to 95%
Ambient pressure Up to 3000 m height without pressure equalization
Room temperature Between 15°C and 35°C
Atmospheric humidity 30% to 75% (on average not higher than 45%, so that there is
no risk of condensation on the placement machine.)
Ambient pressure > 750 mbar (corresponds to 1700 m above mean sea level)
