6 Station extensions Instructio n manual SIPLACE SX1/SX2 Edition V2 and V3 6.7 3D coplanarity laser module From software version SC.713.1 Ed ition 12/2020 324 6.7.2 T echnical data 6 Components QFP, SO, BGA , Gullwing, c…
Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 6 Station extensions
From software version SC.713.1 Edition 12/2020 6.7 3D coplanarity laser module
323
6
6
6
6
WARNING
Laser radiation is hazardous for the eyes
The accessible laser radiation is dangerous for your eyes and, in certain circumstances,
also poses a hazard to skin.
The radiation issued by class 3B lasers (medium output strength) is dangerous during
direct contact with your eyes and also when it is reflected by a mirror. At higher output
levels, this laser could also damage skin.
Avoid looking directly into the laser beam.
The 3D coplanarity module is installed and secured in the placement machine in a
manner which, if used correctly (short radiation periods), fulfills the laser class 2 lim-
its for accessible radiation and is therefore non-hazardous for your eyes.
WARNING
Encapsulated class 2 laser equipment
When in a fixed installation, the placement machine is classified as a so-called "encap-
sulated" class 2 laser device
The 3D sensor is integrated into the emergency OFF circuit.
Never disable the emergency OFF circuit!
The 3D sensor may only be operated inside the placement machine!
WARNING
Repairs and service
For repair and service work, always send the sensors to ASM Assembly Systems
GmbH & Co. KG.
6 Station extensions Instruction manual SIPLACE SX1/SX2 Edition V2 and V3
6.7 3D coplanarity laser module From software version SC.713.1 Edition 12/2020
324
6.7.2 Technical data
6
Components QFP, SO, BGA, Gullwing, connector
Accuracy
*a
± 15 μm (3σ), ± 20 μm (4σ)
Maximum component size 50 x 50 mm²
Maximum component height 17 mm
BGA component shape
Min. ball diameter
Min. ball pitch
Min. number of balls
400
μm
800
μm
6
Gullwing component shape
Min. lead width
*b
Min. lead pitch
Min. number of leads
300
μm
500
μm
5
Maximum connector size 120 x 20 mm²
Connector (Gullwing)
Min. lead width
b
Min. lead pitch
Min. number of leads
300
μm
500
μm
5
Placement head type TwinHead, SIPLACE Multistar CPP
Laser protection class
3D coplanarity sensor
Placement machine
3B
2
*)a Per ball/lead
*)b Contact your local product manager for details of smaller lead widths
Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 6 Station extensions
From software version SC.713.1 Edition 12/2020 6.8 Sensor for the component reject bin
325
6.8 Sensor for the component reject bin
Item no. 00519848-xx query for component reject bin
The sensor for the component reject bin monitors whether the reject bin is seated correctly in its
mount.
– If the reject bin was not inserted correctly, the placement machine cannot be started.
– If the reject bin jumps out of its mount during the placement process, the placement machine
will be stopped immediately to avoid a head crash.
Each reject bin can be monitored by a separate sensor.
6
PLEASE NOTE
When using a SpeedStar we recommend that you install the optional sensor for the com-
ponent reject bin.
