2 Operational safety Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 2.5 Safety instructions for operating the SX1/SX2 placement mac hine From software version SC.713.1 Edition 12/2020 74 2.5.1 1 Safety instructions…
Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 2 Operational safety
From software version SC.713.1 Edition 12/2020 2.5 Safety instructions for operating the SX1/SX2 placement machine
73
2.5.9 Safety instructions for changing the placement head on the TwinStar
2
2.5.10 Safety instructions for docking the component trolley in or out
2
2
2
2
WARNING
Risk of collisions!
When changing the placement head from a TwinStar/VHF to a SpeedStar, the SpeedStar
collides with the camera housing.
Dismantle the stationary cameras of type 33, 55 x 45, and type 25, 16 x 16 for the
TwinStar.
WARNING
Operation only with component trolley!
The placement machine may only be operated if there is a component trolley present and
docked at each location.
Fill any free locations with dummy feeder modules as described in
section 2.6.5
, page 2.6.5.
WARNING
DANGER OF CRUSHING!
Risk of crushing when docking and undocking the component trolley.
Always dock/undock the component trolley alone.
CAUTION
Risk of breaking handles!
Risk of breaking handles when transporting the component trolley.
When transporting the component trolley, do not lift it by its handles.
CAUTION
Risk of injuring limbs!
Risk of injuring limbs when docking and undocking.
When docking and undocking, make sure that there are no body limbs in the travel
area of the component trolley.
2 Operational safety Instruction manual SIPLACE SX1/SX2 Edition V2 and V3
2.5 Safety instructions for operating the SX1/SX2 placement machine From software version SC.713.1 Edition 12/2020
74
2.5.11 Safety instructions for emptying the waste tape container
The waste tape container must be pulled out of the component trolley for emptying. There is a risk
of catching your thumbs as you do so. To prevent this, observe the safety instructions in section
5.8.2
, page 260.
Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 2 Operational safety
From software version SC.713.1 Edition 12/2020 2.6 Safety features
75
2.6 Safety features
2.6.1 Protective covers
The protective hoods and covers serve as protective devices which prevent unauthorized access
to the inside of the placement machine.
2
2
Fig. 2.6 - 1 Protective covers
(1) Protective cover location 1
(2) Protective cover location 2
The travel range of the gantries is protected with two covers which can be opened (items 1 and 2).
CAUTION
Risk of damage!
The protective covers and other covers could be damaged if too much force is exerted.
Do not stand on or climb up the protective covers and other covers.
(1)
(2)
