2 Operational safety Instruction manual SIPLACE SX1/SX2 Edition V2 and V3
2.2 Warning labels From software version SC.713.1 Edition 12/2020
54
2.2.8 Warning labels on the SIPLACE SpeedStar C&P20 P2
2
2
Fig. 2.2 - 11 Warning labels on the SIPLACE SpeedStar C&P20 P2
(1) Temperature label, item no. 03031926-01
(2) Housing for the star motor
(3) Handle
(4) Warning label - risk group 2
Item laser mark - risk class 2, item no. 03155298-01
PLEASE NOTE
Only for SIPLACE SX1/SX2 V3
The SIPLACE SpeedStar C&P20 P2 is only present in the SIPLACE SX1/SX2 V3.
(1)
(3)
(2)
(4)
Laser mark, risk class 2
Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 2 Operational safety
From software version SC.713.1 Edition 12/2020 2.2 Warning labels
55
2.2.8.1 High temperatures on the SIPLACE C&P20 P2
2
1 in fig. 2.2 - 11, page 54 (quantity per SIPLACE C&P20 P2: 1)
2.2.8.2 Laser class 2 on the component sensor
2
Item laser mark - risk class 2 in fig. 2.2 - 11, page 54, (item no. 03155298-01
(quantity per C&P20 P2: 1)
2
High temperatures on the SIPLACE C&P20 P2 during continuous operation
Risk of burns due to high temperatures!
The housing of the star motor and the handle on the placement head may
become very hot during continuous operation and in ambient temperature in
excess of 22 °C.
Be careful when touching the parts.
2
2
2
LASER RADIATION
Risk class 2
Acc. to IEC 60825-1:2014
Do not look into beam!
2 Operational safety Instruction manual SIPLACE SX1/SX2 Edition V2 and V3
2.2 Warning labels From software version SC.713.1 Edition 12/2020
56
2.2.9 Warning labels on the SIPLACE SpeedStar C&P20 P
2
2
Fig. 2.2 - 12 Warning labels on the SIPLACE SpeedStar C&P20 P
(1) Temperature label, item no. 03031926-01
(2) Housing for the star motor
(3) Handle
Item W laser class 2, item no. 03134118-01
PLEASE NOTE
Only for SIPLACE SX1/SX2 V2
The SIPLACE SpeedStar C&P20 P is only present on the SIPLACE SX1/SX2 V2.
(1)
W Laser Klasse 2
(2)
(3)
