Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 5 Tasks at the placement machine From software version SC.713.1 Edition 12/2020 5.15 Docking the c omponent trolley in or out 287 I 5 5 5 Carefully push the componen…
5 Tasks at the placement machine Instruction manual SIPLACE SX1/SX2 Edition V2 and V3
5.15 Docking the component trolley in or out From software version SC.713.1 Edition 12/2020
286
5.15.4 Docking the component trolley
5
Fig. 5.15 - 4 Docking the component trolley
(1) Locking latches
(2) Height setting for fine adjustment to the machine height
5
CAUTION
Pushing in component trolley!
When pushing the component trolley into the placement machine, make sure that
you do not hit obstacles with the locking latches.
(2)
(1)
Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 5 Tasks at the placement machine
From software version SC.713.1 Edition 12/2020 5.15 Docking the component trolley in or out
287
I 5
5
5
Carefully push the component trolley into the placement machine as far as the stop. The stop
block
(2) of the changeover table must fit under the bracket for the table height check (1) on
the machine feed-in (right and left side).
5
Fig. 5.15 - 5 Table height check
5
PLEASE NOTE
Cut tapes flush
If you do not cut tapes off flush at the front end of the X feeder modules, the emptied tapes
will not enter the empty tape duct.
Cut the tapes off flush, before you dock the component trolley into place.
CAUTION
Position of placement head!
Check that the placement head is outside the range of the component trolley.
CAUTION
Risk of head crash!
When dismantling one of the two brackets (left and right side) for the table height check,
there is a risk of a head crash due to changeover tables being too high.
Do not dismantle the brackets.
(1)
(2)
5 Tasks at the placement machine Instruction manual SIPLACE SX1/SX2 Edition V2 and V3
5.15 Docking the component trolley in or out From software version SC.713.1 Edition 12/2020
288
5
Use the height setting for fine adjustment to correct the height of the component trolley. The
two surfaces of the block and the bracket should not quite touch.
5
5
5
Go to the main view of the station software and select the Feeder module... icon and
then the
Locations icon.
Click on the icon to lock the respective location and wait until the trolley has docked
completely. For further information, refer to the station software Online Help.
Push the sleeve up using both handles and swivel the handle
down.
PLEASE NOTE
Close the protective covers since the component trolley can only be docked in if the
covers are closed.
