1 Introduction Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 1.5 Operator levels From software version SC.713.1 Edition 12/202 0 30
Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 1 Introduction
From software version SC.713.1 Edition 12/2020 1.5 Operator levels
29
1.5 Operator levels
Certain functions or menus may only be executed or accessed by specially trained personnel. A
differentiation is made between the following operator levels:
– Production
– Advanced production
– Service (customer)
The operator levels "Advanced production" and "Service (customer)" can be password protected.
Production 1
This operator level includes those people who have been trained to operate the placement ma-
chine. These people are authorized to use any functions associated with operating the placement
machine and may access any menus needed to use the machine.
Advanced production 1
People with this operator level have completed special training and are authorized to perform
setup tasks e.g. creating setup configurations or determining Vision parameters etc.
Service (customer) 1
People with this operator level are specially trained technicians at the customer end, who can, for
example, define machine option settings.
1 Introduction Instruction manual SIPLACE SX1/SX2 Edition V2 and V3
1.5 Operator levels From software version SC.713.1 Edition 12/2020
30
Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 2 Operational safety
From software version SC.713.1 Edition 12/2020 2.1 Safety instructions
31
2 Operational safety
2.1 Safety instructions
2.1.1 Conventions for the use of hazard symbols
This instruction manual contains notes that must be observed to guarantee your personal safety
and to avoid damage to equipment. These notes are highlighted by warning triangles and are in-
dicated as follows according to the level of risk:
2
2
2
2
DANGER
Definition
Danger, as used in this instruction manual, means that death, severe injury or consider-
able damage to equipment will occur if the danger instructions are not followed.
WARNING
Definition
Warning, as used in this instruction manual, means that death, severe injury or consider-
able damage to equipment may occur if the warning instructions are not followed.
CAUTION
Definition
Caution, as used in this instruction manual, means that slight injury or damage to equip-
ment may occur if the caution instructions are not followed.
PLEASE NOTE
Definition
A note, as used in this instruction manual, provides information on the product or indicates
a part of the instruction manual that requires particular attention.
