2 Operational safety
2.1 Safety instructions
2.1.1 Conventions for the use of hazard symbols
This instruction manual contains notes that must be observed to guarantee your personal safety
and to avoid damage to equipment. These notes are highlighted by warning triangles and are in-
dicated as follows according to the level of risk:
2
2
2
2
DANGER
Definition
Danger, as used in this instruction manual, means that death, severe injury or consider-
able damage to equipment will occur if the danger instructions are not followed.
WARNING
Definition
Warning, as used in this instruction manual, means that death, severe injury or consider-
able damage to equipment may occur if the warning instructions are not followed.
CAUTION
Definition
Caution, as used in this instruction manual, means that slight injury or damage to equip-
ment may occur if the caution instructions are not followed.
PLEASE NOTE
Definition
A note, as used in this instruction manual, provides information on the product or indicates
a part of the instruction manual that requires particular attention.
2 Operational safety Instruction manual SIPLACE SX1/SX2 Edition V2 and V3
2.1 Safety instructions From software version SC.713.1 Edition 12/2020
32
2.1.2 Qualified personnel
Qualified or adequately trained personnel means that these people are familiar with the setting up,
operation and preventive maintenance of placement machines and add-on devices and are suit-
ably qualified, e.g.
– have been trained, instructed or authorized to switch on and off, isolate, earth and identify
electrical circuits and system components in accordance with normal safety standards.
– have been trained or instructed in the upkeep and use of appropriate safety equipment in ac-
cordance with normal safety standards.
2.1.3 Important notes on operational safety
The following points MUST be observed in order to maintain operational safety:
2.1.3.1 General
The operational safety of SMD placement machines can be guaranteed only if the system is
used as prescribed and in accordance with the instructions in the user/preventive mainte-
nance manuals.
Always follow any safety regulations specific to your country.
Make sure that the warning labels are always clearly identifiable and always easily readable.
Replace any damaged warning or notice labels. Replace any labels that are missing.
The machine key for releasing the covers on the placement machine must be kept in a safe
place where it is only accessible to qualified staff.
2
If it is necessary to work on the machine and you do not have adequately trained personnel
within your operation, always call in a ASM Assembly Systems GmbH&Co.KG service engi-
neer! ASM Assembly Systems GmbH&Co.KG will not accept liability for any damage or con-
sequential damage that is the result of unauthorized/incorrect work.
PLEASE NOTE
Owner's responsibility
The machine owner, and only the machine owner, is responsible for the safekeeping of
the machine key and for ensuring that it is handed over to authorized persons.
Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 2 Operational safety
From software version SC.713.1 Edition 12/2020 2.1 Safety instructions
33
If particularly hazardous situations are identified while the placement machine is in use, the
placement machine operating company must immediately notify the manufacturer in writing
so that appropriate action can be taken to reduce the potential danger.
2
2.1.3.2 Safety of operators and other persons
Placement machine operators must only carry out work for which they have been adequately
trained and with which they are totally familiar.
NEVER open one of the protective covers if you are not totally familiar with the use and func-
tioning of the placement machine! Do not open the protective covers during operation unless
you are told to do so in this manual or in the station software dialog.
The placement machine may only be operated if there is a component trolley present and
docked at each location.
For your own safety, wear work clothes that conform to the guidelines of the professional as-
sociation or to the regulations of your country, i.e. safety shoes, hair net or no wide sleeves
etc.
Reduce the risks by not wearing scarves, chains or ties at your work post.
People with long hair must wear a protective head covering.
The placement machine may not come into contact with splashed or sprayed water or other
liquids. Cleaning with wet cloths is also prohibited.
In the event of errors, high temperatures could occur at the housings of all motors.
The Z axis of the placement heads is also live with 42 V when the protective cover is open.
For this reason, avoid any work to the Z axis (e.g. manual changing of nozzles). There is a
risk of injuries being caused.
WARNING
Severe injuries and damage to equipment in the case of incorrect usage!
In the event of the placement machine being incorrectly used, movement of the gantries
or lifting tables, for example, could lead to severe injuries and considerable damage to
equipment.
Safe operation of the placement machine requires correct usage by qualified staff with
observance of all warnings.
Some work on the placement machine (e.g. setting up) requires training that goes be-
yond the scope of this manual.
