Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 3 Technical data and assemblies From software version SC.713.1 Edition 12/2020 3.10 X feeder modu les 155 3.10 X feeder modules The SIPLACE SX1/SX2 uses the SIPL ACE S…

3 Technical data and assemblies Instruction manual SIPLACE SX1/SX2 Edition V2 and V3

3.9 PCB conveyor system From software version SC.713.1 Edition 12/2020

154

3.9.6.3 Fiducial criteria

3.9.6.4 Ink spot criteria

Locate 2 fiducials

Locate 3 fiducials

X-/Y-position, rotation angle, mean PCB distortion

additional: shearing, distortion separately in X and Y direction

Fiducial shapes Synthetic fiducials: circle, cross, square, rectangle, diamond,

circular, square and rectangular contours, double cross

Pattern: any

Fiducial surface

Copper

Tin

Without oxidation and solder resist

Warp

≤ 1/10 of structure width, both with good contrast to

environment

Dimensions of synthetic fiducials

Min. X/Y size for circle and rectangle:

Min. X/Y size for annulus and rectangle:

Min. X/Y size for cross:

Min. X/Y size for double-cross:

Min. X/Y size for rhombus:

Min. frame width for annulus and rectangle:

Min. bar width / bar distance for cross, double-cross:

Max. X/Y size for all fiducial shapes:

Max. bar width for cross, double-cross:

Min. tolerances, general:

Max. tolerances, general:

0.25 mm

0.3 mm

0.5 mm

0.35 mm

0.1 mm

3 mm

1.5 mm

2% of nominal dimension

20% of nominal dimension

Dimensions of patterns

Min. size

Max. size

0.5 mm

3 mm

Fiducial environment Clearance around reference fiducial not necessary if there is no

similar fiducial structure in the search area.

Methods - Synthetic fiducial recognition method

- Mean grayscale value

- Histogram method

- Template matching

Shapes and sizes of fiducials/

structures for

Synthetic fiducials

Other methods

For dimensions of synthetic fiducials, see Section 3.9.6.3

Fidu-

cial criteria, page 154.

Min. 0.3 mm

Max. 5 mm

Masking material Good coverage

Recognition time Depends on the method: 20 ms - 0.2s

Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 3 Technical data and assemblies

From software version SC.713.1 Edition 12/2020 3.10 X feeder modules

155

3.10 X feeder modules

The SIPLACE SX1/SX2 uses the SIPLACE SmartFeeder X and the SIPLACE SmartFeeder Xi.

The specified SIPLACE tape feeder modules are compatible with the SIPLACE SX1/SX2 change-

over tables. Key features of the SIPLACE tape feeder modules include high pickup position pre-

cision, online programming and simple handling of feeder module changeovers during the

placement process. The power supply to the feeder modules is contactless and uses an inductive

interface. Each feeder module communicates with the feeder module control unit (FCU) via two

optoelectronic channels (optical fiber). The two interfaces form the EDIF assembly (energy and

data interface).

3.10.1 SIPLACE tape feeder module

3.10.1.1 Tape material

The possible tape widths range from 4 mm to 104 mm. The tape material is blister or paper. Com-

ponent tapes with a permanently adhesive cover foil (PSA foil) can also be processed.

The design of the tape feeder modules was based on the following tape standards:

DIN EN 60286-3 (12/1998) / IEC 60286-3 (12/1997)

JIS C 0806-3 (1999)

ANSI/EIA 481-C (10/2003)

IEC 60286-3-2

3.10.1.2 Manual removal of tantalum capacitors which were not picked up

To prevent tantalum capacitors which were not picked up from causing the tape material to burn

when it is cut, the user interface has been extended to include the option "Stop immediately on

pickup error". This option must be enabled in SIPLACE Pro. On the placement machine, the com-

ponent that was not picked up is paced forward again until it is ready for removal from the com-

ponent tape. The track is deactivated and the operator is sent an error message to remind him to

pick up the tantalum component from the tape. If an alternative track is available, the placement

machine continues placing. The operator is able to stop the placement machine, however, and re-

move the tantalum component. If no alternative track is available and it is not possible to continue

placement with other components, the placement machine will stop. At this point, the operator can

again remove the tantalum component and acknowledge the error. Once the operator has re-

started the placement machine, placement is continued and components are picked up from the

track that is now enabled once more.

PLEASE NOTE

This software function is also a good idea for expensive components.

 Please observe the safety instructions for capacitors on metallic powder basis (see

section 2.5.3

, page 68).

3 Technical data and assemblies Instruction manual SIPLACE SX1/SX2 Edition V2 and V3

3.10 X feeder modules From software version SC.713.1 Edition 12/2020

156

3.10.1.3 Design of the SIPLACE SmartFeeder X

The following diagram shows the design of the SIPLACE SmartFeeder X.

Fig. 3.10 - 1 SIPLACE SmartFeeder X

(1) Entry to the tape guide channel with tape spring

(2) Flap on cover foil container

(3) Removal handle, engaged

(4) Status display

(5) Operating panel - LED display

(6) Foil rocker

(7) Tape guide channel outlet

(8) Front slider guide

(9) Back slider guide

(1)

(2)

(3)

(4)

(5)

(6)

(

(7)
