2 Operational safety Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 2.2 Warning labels From software version SC.713.1 Edition 12/2020 58 2.2.10 W arning labels on th e SIPLACE MultiSt ar CPP 2 Fig. 2.2 - 13 Warning…
Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 2 Operational safety
From software version SC.713.1 Edition 12/2020 2.2 Warning labels
57
2.2.9.1 High temperatures on the SIPLACE C&P20 P
2
1 in fig. 2.2 - 12, page 56 (quantity per SIPLACE C&P20 P: 1)
2.2.9.2 Laser class 2 on the component sensor
2
Item W laser class 2 in fig. 2.2 - 12, page 56, item no. 03134118-01 (quantity per C&P20 P: 1)
2
High temperatures on the SIPLACE C&P20 P during continuous operation
Risk of burns due to high temperatures!
The housing of the star motor and the handle on the placement head may
become very hot during continuous operation and in ambient temperature in
excess of 22 °C.
Be careful when touching the parts.
2
2
2
LASER RADIATION
Laser class 2
Acc. to IEC 60825-1:2014
Do not look into beam!
2 Operational safety Instruction manual SIPLACE SX1/SX2 Edition V2 and V3
2.2 Warning labels From software version SC.713.1 Edition 12/2020
58
2.2.10 Warning labels on the SIPLACE MultiStar CPP
2
Fig. 2.2 - 13 Warning labels on the SIPLACE MultiStar CPP
(1) Temperature label, item no. 03031926-01
Item laser mark - risk class 2, item no. 03155298-01
(1)
Laser mark, risk class
Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 2 Operational safety
From software version SC.713.1 Edition 12/2020 2.2 Warning labels
59
2.2.10.1 High temperatures on the SIPLACE CPP
2
1 in fig. 2.2 - 13, page 58 (quantity per SIPLACE CPP: 1)
2.2.10.2 Laser class 2 on the component sensor
2
Item W laser class 2 in fig. 2.2 - 13, page 58, item no. 03134118-01 (quantity per CPP: 1)
2
High temperatures on the SIPLACE CPP during continuous operation
Risk of burns due to high temperatures!
The
Z drive (linear motor) can develop high surface temperatures during
continuous operation, if the ambient temperature is greater than 22°C.
Be careful when touching the parts.
2
2
2
LASER RADIATION
Laser class 2
Acc. to IEC 60825-1:2014
Do not look into beam!
