4 Setting up and commissioning Instruction manual SIPLACE SX1/SX2 Edition V2 and V3
4.1 Transportation and delivery configuration From software version SC.713.1 Edition 12/2020
186
4.1.4 Transporting the placement machine in the crate
4.1.4.1 Services
As a special service, SIPLACE offers to realize the complete integration of your SIPLACE place-
ment machine in your production line. With our extensive expertise and by using the right tools
and equipment, we can ensure that the installation process runs smoothly and efficiently. How-
ever, this will require you to clarify the infrastructure aspects in advance and make any necessary
changes at your production facility.
Please note that the safest way to transport the placement machine is always in the transport crate
- or at the very least on the pallet. This will prevent serious damage to the placement machine
caused by the feet colliding with obstacles, for example.
4.1.4.2 Safety instructions
4
4
4
4.1.4.3 Means of transport
To transport the placement machine on a palette or on a transportation crate, use a fork lift truck
with the following specifications:
Fork length: Min. 1800 mm
Carrying power: Min. 6,000 kg
Clear width between forks: Min. 350 mm
4
4
WARNING
Observe the applicable accident prevention regulations!
The applicable accident prevention regulations concerning the transportation of
heavy goods must be followed.
WARNING
Risk of tilting!
Risk of tilting, if the required specifications for the fork-lift truck are not observed (section
4.1.4.3
, page 186) !
Only use the specified fork-lift for transportation.
WARNING
DANGER OF CRUSHING!
Risk of crushing feet when transporting the placement machine.
Wear special protective shoes.
Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 4 Setting up and commissioning
From software version SC.713.1 Edition 12/2020 4.1 Transportation and delivery configuration
187
4.1.4.4 Fork-lift attachment points on the transport crate or pallet
Position the fork-lift truck only at the points marked (A). in fig. 4.1 - 1, page 183. We recommend
that you keep the crate or the pallet with packaging for later use.
4
4
4.1.5 Transporting the placement machine without a crate or pallet
4.1.5.1 Safety instructions
4
4
4
4
WARNING
Damage to property on the placement machine!
There is a risk of damaging the placement machine if it is transported without crate or pal-
let.
Observe the information in the next section.
WARNING
Observe the applicable accident prevention regulations!
The applicable accident prevention regulations concerning the transportation of
heavy goods must be followed.
WARNING
DANGER OF CRUSHING!
Risk of crushing feet when transporting the placement machine.
Wear special protective shoes.
WARNING
Damage to property on the placement machine!
There is a risk of damaging the placement machine if it is transported without crate or pal-
let.
Read this section through completely before transporting the machine.
WARNING
Risk of damage!
The thread for the machine feet in the machine frame could be damaged by being
dragged along the floor or from impact.
When you are transporting the machine, make sure that all the feet are clear of the
floor.
4 Setting up and commissioning Instruction manual SIPLACE SX1/SX2 Edition V2 and V3
4.1 Transportation and delivery configuration From software version SC.713.1 Edition 12/2020
188
4.1.5.2 Means of transport
Use a fork-lift truck with the following specification to carry the placement machine:
4.1.5.3 Fork-lift attachment points on the placement machine
The diagram 4.1 - 3, page 189 shows the fork-lift attachment points on the placement machine for
lifting the placement machine off the pallet or transporting it without the pallet.
4
Please note the following warnings before you raise the placement machine in order to avoid
irreversible damage to the placement machine:
4
4
Fork length Min. 1800 mm
Lifting power Min. 6,000 kg
Distance between forks with the forks running parallel
to the direction of PCB transport
Approx. 420 mm
PLEASE NOTE
Avoiding damage to the placement machine
When transporting the placement machine over longer distances, always use a pallet
and fork lift.
WARNING
Aligning the forks
– The forks must be aligned parallel to the PCB conveyor.
– The forks must be aligned parallel to the placement machine.
WARNING
Risk of damage due to excessive fork spacing!
Increased fork spacing, which means that the placement machine is raised at points out-
side its contact surface, can lead to deformation of the placement machine frame and
cause damage to cables and lines.
The forks may only be opened to a degree which ensures that they are still within the
contact area of the machine underside (see fig. 4.1 - 3
, page 189).
