3 Technical data and assemblies I nstruction manual SIPLACE SX1/S X2 Edition V2 and V3 3.11 Component trolley From software version SC.713.1 Edition 12/ 2020 174 3.1 1.4 Fiducials on the component trolley 3 Fig. 3.1 1 - …
Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 3 Technical data and assemblies
From software version SC.713.1 Edition 12/2020 3.11 Component trolley
173
3.11.3 Technical data
3
Component trolley dimensions
Component trolley with 60 tracks (length x
width)
Component trolley with 30 tracks (length x
width)
760 mm x 864 mm
760 mm x 471 mm
Height with folded-up handles
900 mm (PCB transport height:
930 mm (PCB transport height:
950 mm (PCB transport height:
934 mm
964 mm
984 mm
Weight of component trolley with 60 tracks
Without feeder modules
With feeder modules (fully configured)
Weight of component trolley with 30 tracks
Without feeder modules
With feeder modules (fully configured)
104 kg
266 kg
76 kg
157 kg
Tape reel diameter
Standard
maximum
to 432 mm (17“)
483 mm (19“)
Feeder locations
Component trolley with 60 tracks
Component trolley with 30 tracks
60 feeders with 8 mm
30 feeders with 8 mm
Component trolley changeover time < 1 minute
3 Technical data and assemblies Instruction manual SIPLACE SX1/SX2 Edition V2 and V3
3.11 Component trolley From software version SC.713.1 Edition 12/2020
174
3.11.4 Fiducials on the component trolley
3
Fig. 3.11 - 3 Fiducials on the component trolley
(1) Fiducials on the component trolley
Once the component trolley has been docked in, the placement machine measures the
fiducials on the component trolley.
For components with an edge length of less than 0.5 mm, i.e. 0402 components and smaller, the
position of the component is determined with the tape pocket before the first component is picked
up.
(1)
Instruction manual SIPLACE SX1/SX2 Edition V2 and V3 3 Technical data and assemblies
From software version SC.713.1 Edition 12/2020 3.11 Component trolley
175
3.11.5 Dimensions of the component trolley
3
Fig. 3.11 - 4 Dimensions of the component trolley, SIPLACE SX1/SX2, all dimensions in millimeters
(1) Length = 760 mm
(2) Width = 864 mm
(3) Height (depends on the height setting
– For 900 mm = 934 mm
– For 930 mm = 964 mm
– For 950 mm = 984 mm
(4) Distance between handles when folded open = 476 mm
