3.5 "Recog. Error" T ab Displayed is the recognition error data of the current model. • Sheet Layout When the "Recog. Error" tab is pressed in the "PRGM. MNG. DA T A" window (submenu), the f…
*12 Error Stop Time
This indicates the period of time ("*13 Error Alarm Time" + "*14
Recovery Time") during which the machine was reset to its normal
condition after an error alarm was issued.
*13 Error Alarm Time
This indicates the period of time during which the machine issued
an error alarm.
*14 Recovery Time
This indicates the period of time required for the machine to be
reset to its normal condition.
*15 Others
This indicates the period of time required for setup, program change,
and idling operations.
*16 Test Mode Time
This indicates the period of time during which the machine was
operated in the "TEST" mode (operation mode).
*17 SET-UP Time
This indicates the period of time during which the [OPERATION/
SET UP] switch on the front operation panel was set to the "SET
UP" side.
0106-002 Chapter 1 3 24 AFU01EDTP
3.4
"
Time Data
"
Tab
3.5 "Recog. Error" Tab
Displayed is the recognition error data of the current model.
• Sheet Layout
When the "Recog. Error" tab is pressed in the "PRGM. MNG. DATA"
window (submenu), the following tab sheet appears.
Fig. 3C17 "Recog. Error" Tab Sheet
• Sheet Composition
*1 #1 ERROR (/Total P.E.C. Error)
This indicates the total number of errors on the first fiducial mark
and the ratio based on the total number of P.E.C. recognition er-
rors.
*2 #2 ERROR (/Total P.E.C. Error)
This indicates the total number of errors on the second fiducial
mark and the ratio based on the total number of P.E.C. recognition
errors.
*3 #3 ERROR (/Total P.E.C. Error)
Not Available
*4 Total P.E.C. Recog. Error
This indicates the total number of errors that were detected in P.E.C.
recognition processing.
*1
*2
*3
*4
0106-002 Chapter 1 3 25 AFU01EDTP
3.5
"
Recog. Error
"
Tab
0004-001 Chapter 1 3 26 AFQ01EDTP
