Error ID Item Description 0513000 Squeegee Drive Front squeegee was down. Interlock (Cause 1) The front squeegee upper limit and middle sensors (BPS060 and BPS061) are defective. (Cause 2) The operation timing is shifted…
Error ID Item Description
0505000 Squeegee Driving Driver alarm signal was detected.
Servo
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If this operation does not reset the machine to its normal condition, con-
tact our service personnel for details.
0508000 Squeegee Driving Driver Over-Heat
Servo
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If this operation does not reset the machine to its normal condition, con-
tact our service personnel for details.
0509000 Squeegee Drive Operation was incompleted, within specified time.
Servo
(Cause 1) The driver is malfunctioning or an error has occurred during communication
with the host CPU
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, perform the zeroing operation.
If this operation does not reset the machine to its normal condition, the
driver may be defective. Contact our service personnel for details.
2.3 Error IDs and Remedial Procedures
0106-002 Chapter 2 2 24 AFU01ETRP
Error ID Item Description
0513000 Squeegee Drive Front squeegee was down.
Interlock
(Cause 1) The front squeegee upper limit and middle sensors (BPS060 and BPS061)
are defective.
(Cause 2) The operation timing is shifted from the normal one.
(Cause 3) The squeegee driving axis was activated after the front squeegee had moved
down.
(during the manual operation)
(Remedy 1) Check how the sensors are working in “Device Check” window (submenu).
When the sensors are not working, it is required to replace the sensors
with new ones. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine
again. After that, restart the operation. When the same error still occurs,
contact our service personnel for details.
(Remedy 3) Perform the zeroing operation and re-start the operation.
0514000 Squeegee Driving Rear squeegee was down.
Interlock
(Cause 1) The rear squeegee upper limit and middle sensors (BPS062 and BPS063)
are defective.
(Cause 2) The operation timing is shifted from the normal one.
(Cause 3) The squeegee driving axis was activated after the rear squeegee had moved
down.
(during the manual operation)
(Remedy 1) Check how the sensor are working in “Device Check” window (submenu).
When the sensor are not working, it is required to replace the sensors
with new ones. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
(Remedy 3) Perform the zeroing operation and re-start the operation.
2.3 Error IDs and Remedial Procedures
0106-002 Chapter 2 2 25 AFU01ETRP
Error ID Item Description
0515000 Squeegee Driving Task has not been completed unable to continue.
Timing
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If the machine is not reset to its normal condition, shut down the power of
the machine once and power up the machine again. After that, re-start
the operation. When the same error still occurs, contact our service per-
sonnel for details.
0516000 Squeegee Driving The data was detected outside of the possible range.
Data
(Cause 1) The specified data may have exceeded the movable range.
(Remedy 1) Check the parameters in the “Print Margin”, “Paste Size” (“OPN. MODE”
window) and “Print Area” (“Pattern Program” window) text boxes.
0517000 Squeegee Driving Zeroing Opn. Not Complete
Origin
(Cause 1) The motor axis was activated before the zeroing operation was completed.
(Remedy 1) Perform the zeroing operation.
0601000 P.E.C. Recognition Operation was incompleted, within specified time.
Camera X Origin
(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 2) The sensor is defective.
(Cause 3) The driver is malfunctioning or an error has occurred during communication
with the host CPU.
(Remedy 1) Wipe off dirt on the sensor and zero the P.E.C. recognition camera X axis
again.
(Remedy 2) It is required to replace the sensor with a new one. Contact our service
personnel for details.
(Remedy 3) Shut down the power of the machine once and power up the machine
again. After that, perform the zeroing operation.
If this operation does not reset the machine to its normal condition, the
driver may be defective. Contact our service personnel for details.
2.3 Error IDs and Remedial Procedures
0106-002 Chapter 2 2 26 AFU01ETRP
