Error ID Item Description 0219000 T able Z T iming T ask has not been completed unable to continue. (Cause 1) Self-Diagnostics Error Message (Remedy 1) Zero all axes and re-start the operation. If the machine is not rese…
Error ID Item Description
0217000 Table Z Interlock (-) Limit error has been detected.
(Cause 1) The table θ limit (-) photosensor (BPH213) is defective.
(Cause 2) The operation timing is shifted from the normal one.
(Cause 3) When this error occurs during a manual operation, it is not regarded as a
device error.
(Remedy 1) Check how the sensor is working in “Device Check” window (submenu).
When the sensor is not working, it is required to replace the sensor with
a new one. Contact our service personnel for details.
(Remedy 2) Shut off the power to the machine once and power up the machine again.
After that, re-start the operation.
When the same error still occurs, contact our service personnel for de-
tails.
(Remedy 3) Perform the zeroing operation and re-start the operation.
0218000 Table Z Interlock P.E.C Recog-Y Axis is not at safety area.
(Cause 1) The P.E.C. recognition Y-axis interlock sensor (BPH046) is defective.
(Cause 2) The operation timing is shifted from the normal one.
(Cause 3) The table Z axis was activated when the P.E.C. recognition Y-axis was not
located at its rear escape position.
(during the manual operation)
(Remedy 1) Check how the sensor is working in “Device Check” window (submenu).
When the sensor is not working, it is required to replace the sensor with
a new one. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
(Remedy 3) Perform the zeroing operation and re-start the operation.
2.3 Error IDs and Remedial Procedures
0106-002 Chapter 2 2 15 AFU01ETRP
Error ID Item Description
0219000 Table Z Timing Task has not been completed unable to continue.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If the machine is not reset to its normal condition, shut down the power of
the machine once and power up the machine again. After that, re-start
the operation.
When the same error still occurs, contact our service personnel for de-
tails.
0220000 Table Z Data The data was detected outside of the possible range.
(Cause 1) The specified data may have exceeded the movable range.
(Remedy 1) Check the parameters in the “Screen Distance” (“Pattern Program” win-
dow), “Screen Distance” (“OFFSET DATA” window), and “P.C.B. Trans-
fer Height” (“OFFSET DATA” window) text boxes.
0221000 Table Z Origin Zeroing Opn. Not Complete
(Cause 1) The motor axis was activated before the zeroing operation was completed.
(Remedy 1) Perform the zeroing operation.
0301000 Table
θθ
θθ
θ Origin Zeroing opn. was incompleted, within specified time.
(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 2) The sensor is defective.
(Cause 3) The driver is malfunctioning or an error has occurred during communication
with the host CPU.
(Remedy 1) Wipe off dirt on the sensor and zero Table θ again.
(Remedy 2) It is required to replace the sensor with a new one. Contact our service
personnel for details.
(Remedy 3) Shut down the power of the machine once and power up the machine
again. After that, perform the zeroing operation.
If this operation does not reset the machine to its normal condition, the
driver may be defective. Contact our service personnel for details.
2.3 Error IDs and Remedial Procedures
0106-002 Chapter 2 2 16 AFU01ETRP
Error ID Item Description
0302000 Table
θθ
θθ
θ Origin Detect lost pulse error.
(Cause 1) The motor is overloaded and has a loss of synchronism.
(Remedy 1) Check for any obstacle around the table θ axis and then perform the
zeroing operation.
If this operation does not reset the machine to its normal condition, con-
tact our service personnel for details.
0303000 Table
θθ
θθ
θ Limit (+)Limit error has been detected.
0304000 Table
θθ
θθ
θ Limit (-)Limit error has been detected.
(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 2) The sensor is defective.
(Cause 3) The driver is malfunctioning or an error has occurred during communication
with the host CPU.
(Remedy 1) Wipe off dirt on the sensor and zero Table X again.
(Remedy 2) It is required to replace the sensor with a new one. Contact our service
personnel for details.
(Remedy 3) Shut down the power of the machine once and power up the machine
again. After that, perform the zeroing operation.
If this operation does not reset the machine to its normal condition, the
driver may be defective. Contact our service personnel for details.
0305000 Table
θθ
θθ
θ Servo Driver alarm signal was detected.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If this operation does not reset the machine to its normal condition, con-
tact our service personnel for details.
0308000 Table
θθ
θθ
θ Servo Driver Over-Heat
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If this operation does not reset the machine to its normal condition, con-
tact our service personnel for details.
2.3 Error IDs and Remedial Procedures
0106-002 Chapter 2 2 17 AFU01ETRP
