Error ID Item Description 071 1000 P .C.B. Recognition P .C.B. stopper was down. Camera Y Interlock (Cause 1) The P .E.C. recognition Y axis is moved during the P .C.B. stopper is moved down. (Cause 2) The P .C.B. stoppe…
Error ID Item Description
0708000 P.E.C. Recognition Driver Over-Heat
Camera Y Servo
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If this operation does not reset the machine to its normal condition, con-
tact our service personnel for details.
0709000 P.E.C. Recognition Operation was incompleted, within specified time.
Camera Y Servo
(Cause 1) The driver is malfunctioning or an error has occurred during communication
with the host CPU
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, perform the zeroing operation.
If this operation does not reset the machine to its normal condition, the
driver may be defective. Contact our service personnel for details.
0710000 P.E.C. Recognition Table-Z Axis is not at origin.
Camera Y Interlock
(Cause 1) The table Z axis origin sensor (BPH171) is defective.
(Cause 2) The operation timing is shifted from the normal one.
(Cause 3) The P.E.C. recognition Y axis was activated after the table Z axis had moved
up. (during the manual operation)
(Remedy 1) Check how the sensor is working in "Device Check" window (submenu).
When the sensor is not working, it is required to replace the sensor with
a new one. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine
again. After that, restart the operation. When the same error still occurs,
contact our service personnel for details.
(Remedy 3) Perform the zeroing operation and re-start the operation.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 31 AFU01ETRP
Error ID Item Description
0711000 P.C.B. Recognition P.C.B. stopper was down.
Camera Y Interlock
(Cause 1) The P.E.C. recognition Y axis is moved during the P.C.B. stopper is moved
down.
(Cause 2) The P.C.B. stopper upper limit (BPS070) is defective.
(Remedy 1) Move up the P.C.B. stopper and re-start the operation.
(Remedy 2) Adjust the sensor position.
If this operation does not reset the machine to its normal condition, it is
required to replace the sensor with a new one. Contact our service per-
sonnel for details.
0712000 P.E.C. Recognition P.C.B. warpage protection was down.
Camera Y Interlock
(Cause 1) The P.E.C. recognition Y axis is moved during the P.C.B. warpage protec-
tion is moved down.
(Remedy 1) Move up the P.C.B. warpage protection and re-start the operation.
0713000 P.E.C. Recognition Cleaning nozzle is up.
Camera Y Interlock
(Cause 1) The cleaning nozzle lower limit sensor (BPS081) is defective.
(Cause 2) The operation timing is shifted from the normal one.
(Cause 3) The P.E.C. recognition Y axis is moved during the cleaning nozzle is moved
up.(during the manual operation)
(Remedy 1) Check how the sensor is working in "Device Check" window (submenu).
When the sensor is not working, it is required to replace the sensor with
a new one. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
(Remedy 3) Perform the zeroing operation and re-start the operation.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 32 AFU01ETRP
Error ID Item Description
0714000 P.E.C. Recognition Task has not been completed unable to continue.
Camera Y Timing
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If the machine is not reset to its normal condition, shut down the power of
the machine once and power up the machine again. After that, re-start
the operation. When the same error still occurs, contact our service per-
sonnel for details.
0716000 P.E.C. Recognition Zeroing Opn. Not Complete
Camera Y Origin
(Cause 1) The motor is moved without completing the zeroing operation.
(Remedy 1) Perform the zeroing operation.
0801000 Screen Recognition Zeroing opn. was incompleted, within specified time.
Camera X Origin
(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 2) The sensor is defective.
(Cause 3) The driver is malfunctioning or an error has occurred during communication
with the host CPU.
(Remedy 1) Wipe off dirt on the sensor, and zero the screen recognition X axis again.
(Remedy 2) It is required to replace the sensor with a new one. Contact our service
personnel for details.
(Remedy 3) Shut down the power of the machine once and power up the machine
again. After that, perform the zeroing operation.
If this operation does not reset the machine to its normal condition, the
driver may be defective. Contact our service personnel for details.
0802000 Screen Recognition Detect lost pulse error.
Camera X Origin
(Cause 1) The motor is overloaded and has a loss of synchronism.
(Remedy 1) Execute the origin return after confirming whether there is obstacle in the
vicinity of screen recognition X axis.
If this operation does not reset the machine to its normal condition, con-
tact our service personnel for details.
2.3 Error IDs and Remedial Procedures
