Error ID Item Description 1901042 Screen Fiducial Recognition system error . Mark #1 1901043 Screen Fiducial Recognition system error . Mark #1 1901044 Screen Fiducial Could not get image at normal light. Mark #1 1901045…
Error ID Item Description
1901024 Screen Fiducial [Recog.Area Y] exceeds the range of setting.
Mark #1
1901025 Screen Fiducial [Color] exceeds the range of setting.
Mark #1
1901026 Screen Fiducial Could not get Screen image.
Mark #1
1901027 Screen Fiducial X-cordinate error of measuring point was extensive.
Mark #1
1901028 Screen Fiducial Y-cordinate error of measuring point was extensive.
Mark #1
1901029 Screen Fiducial Image around fiducial mark was unstable.
Mark #1
1901030 Screen Fiducial Error of mark figure similitude was extensive.
Mark #1
1901031 Screen Fiducial Error of mark similitude or mark size was extensive.
Mark #1
1901032 Screen Fiducial Specified mark was not found in window of recog.monitor.
Mark #1
1901033 Screen Fiducial Unavailable camera magnification was set.
Mark #1
1901034 Screen Fiducial Abnormal data was transferred to recog.unit.
Mark #1
1901035 Screen Fiducial Unavailable fiducial mark code was set.
Mark #1
1901036 Screen Fiducial Unavailable fiducial mark size D1 was set.
Mark #1
1901037 Screen Fiducial Unavailable fiducial mark size D2 was set.
Mark #1
1901038 Screen Fiducial Unavailable fiducial mark polality was set.
Mark #1
1901039 Screen Fiducial Unavailable fiducial mark angle was set.
Mark #1
1901040 Screen Fiducial Unavailable fiducial mark area was set.
Mark #1
1901041 Screen Fiducial JIG not found
Mark #1
(Cause 1) Same as "Fiducial Mark #1"
(Remedy 1) Same as "Fiducial Mark #1"
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 65 AFU01ETRP
Error ID Item Description
1901042 Screen Fiducial Recognition system error.
Mark #1
1901043 Screen Fiducial Recognition system error.
Mark #1
1901044 Screen Fiducial Could not get image at normal light.
Mark #1
1901045 Screen Fiducial Could not get image at ring light.
Mark #1
1901046 Screen Fiducial Field no. was out of range.
Mark #1
1901047 Screen Fiducial Pinting test failed.
Mark #1
1901048 Screen Fiducial Could not get screen image
Mark #1
1901049 Screen Fiducial Could not move indpection window.
Mark #1
1901050 Screen Fiducial Could not cut indpection window.
Mark #1
1901051 Screen Fiducial Could not soecified opening area size.
Mark #1
1901052 Screen Fiducial Could not send inspection window data.
Mark #1
1901053 Screen Fiducial Could not reimage bridge insoection window.
Mark #1
1901054 Screen Fiducial Could not reimage bridge insoection window(rotation).
Mark #1
1901055 Screen Fiducial PAD area soze exceeds the max eange(6.5mm
2
).
Mark #1
1901056 Screen Fiducial Recog. transaction time over.
Mark #1
(Cause 1) Same as "Fiducial Mark #1"
(Remedy 1) Same as "Fiducial Mark #1"
1902000 Screen Fiducial (Same as "Fiducial Mark #1")
Mark #2
(Cause 1) Same as "Fiducial Mark #1"
(Remedy 1) Same as "Fiducial Mark #1"
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 66 AFU01ETRP
Error ID Item Description
1904000 Screen Recognition (Same as "Fiducial Mark #1")
Test
(Cause 1) Same as "Fiducial Mark #1"
(Remedy 1) Same as "Fiducial Mark #1"
1906000 Screen Recognition (Same as "Fiducial Mark #1")
Camera
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
2001000 Cleaning Interlock P.E.C Recog-Y Axis is not at safety area.
(Cause 1) The cleaning nozzle was moved up when the P.C.B. recognition Y axis was
not located at its front escape position (origin position).
(during the manual operation)
(Cause 2) The P.C.B. recognition Y-axis near origin sensor (BPH331) is defective.
(Cause 3) The operation timing is shifted from the normal one.
(Remedy 1) Zero the P.C.B. recognition Y axis and re-start the operation.
(Remedy 2) Zero the P.C.B. recognition Y axis.
When the P.C.B. recognition Y axis cannot be zeroed, it is required to
replace the sensor with a new one. Contact our service personnel for
details.
(Remedy 3) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
