Error ID Item Description
2108000 Operator's Error P.C.B. was took on output conveyor.
(Cause 1) Although a manual operation cannot be implemented with a P.C.B. on the
output conveyor, such an operation was performed with a P.C.B.
(Remedy 1) Remove the P.C.B. on the output conveyor and re-start the operation.
2109000 Operator's Error P.C.B. removed from output conveyor.
(Cause 1) Although a manual operation cannot be implemented without a P.C.B. on
the output conveyor, such an operation was performed without a P.C.B.
(Remedy 1) Place a P.C.B. on an area of the output conveyor where the sensor re-
acts.
2113000 Operator's Error Vacuum cleaning can not use in vacuum plate chuck on.
(Cause 1) The operation timing is shifted from the normal one.
(Cause 2) A cleaning suction operation was performed during the vacuum cleaning
(chuck suction). (during the manual operation)
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
(Remedy 2) Cancel the chuck suction operation through manual operation and re-
start the operation.
2114000 Operator's Error Vacuum plate can not use at vacuum cleaning on.
(Cause 1) The operation timing is shifted from the normal one.
(Cause 2) A chuck suction operation was performed during the vacuum cleaning (chuck
suction). (during the manual operation)
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
(Remedy 2) Cancel the cleaning suction operation through manual operation and re-
start the operation.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 70 AFU01ETRP
Error ID Item Description
2115000 Operator's Error Input conveyor width was out of specified range.
2116000 Operator's Error Table chute width was out of specified range.
2117000 Operator's Error Output conveyor width was out of specified range.
(Cause 1) The P.C.B. dimension (Y) in the current pattern program differs extremely
from the input conveyor width.
(Remedy 1) Open the "ALL PROD. CHG." window and change the conveyor width.
2118000 Operator's Error Screen recog. was not finished.
(Cause 1) An operation was performed to check the results of the screen recognition
although no screen recognition operation is performed yet.
(Remedy 1) Perform the screen recognition.
2121000 Operator's Error Not printed P.C.B. exists on the table.
(Cause 1) An unprinted P.C.B. was discharged during the automatic operation after an
error was canceled.
(Remedy 1) Remove the unprinted P.C.B. on the table and re-start the operation.
Click the table section (illustrated) in the "AUTO OPN." window to re-
move the P.C.B. from the memory of the machine whenever necessary.
2122000 Operator's Error Screen was not found.
(Cause 1) The screen clamping cancel check sensor (BPS094) is turned OFF.
(Remedy 1) Install the screen and re-start the operation.
When an error occurs even though the screen is installed, it is required to
adjust the sensor position or replace the sensor with a new one.
Contact our service personnel for details.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 71 AFU01ETRP
Error ID Item Description
2123000 Operator's Error Reference position was not identified.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Perform the teaching operation again from the beginning.
2124000 Operator's Error Screen was on the holder.
(Cause 1) The screen clamping cancel check sensor (BPS094) is turned ON.
(Remedy 1) Detach the screen and re-start the operation.
When this error still occurs even though the screen is detached, it is
required to adjust the sensor position or replace the sensor with a new
one. Contact our service personnel for details.
2201000 Vacuum Pump Vacuum sw was not ON, within specified time.
(Cause 1) The vacuum plate is not used.
(Cause 2) Vacuum Leakage
(Cause 3) The vacuum switch is defective.
(Remedy 1) When the vacuum plate is not used, specify the vacuum plate in the pat-
tern program.
(Remedy 2) Check for vacuum leakage between the P.C.B. and the vacuum plate.
(Remedy 3) The vacuum switch might be set incorrectly or the main body of the vacuum
switch might be defective.
Contact our service personnel for details.
2202000 Vacuum Pump Cleaning side change timeover
(Cause 1) The suction changeover cylinder might be malfunctioning or the cylinder
sensor might be defective.
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
2.3 Error IDs and Remedial Procedures
