2.4 "Option Setting" T ab When the external keyboard (option) is used, this sheet can be used to change the configuration of the system. • Sheet Layout When the "Option Setting" tab is pressed in the …
• Sheet Composition
*1 Monitor Protection
The monitor protection function can be activated to avoid burning
the screen. The screen is automatically blanked.
When you turn on the check box, the check mark (;) appears
inside the box, indicating that the touch screen is set in the monitor
protection mode.
*2 Wait Time (min)
When the touch screen is set in the monitor protection mode, enter
the period of time during which the ten-key window or the virtual
keyboard is made visible and the touch screen is automatically
blanked after the last touch on the touch screen.
The input range is "01 to 99 minutes" in increments of 1 minute.
*3 Language
Either "Japanese" or "English" can be selected.
Turn on the desired option button. A dot appears inside the circle,
indicating that the desired language is selected. After that, press
the [Save] button on the toolbar.
All labels are expressed in the selected language.
0009-002 Chapter 1 4 14 AFU01EDTP
2.3
"
Display Setting
"
Tab
2.4 "Option Setting" Tab
When the external keyboard (option) is used, this sheet can be used to
change the configuration of the system.
• Sheet Layout
When the "Option Setting" tab is pressed in the "MAC. SET-UP" win-
dow (submenu), the following tab sheet appears.
Fig. 3D10 "Option Setting" Tab Sheet
• Sheet Composition
*1 External Keyboard
The configuration of the system can be changed such that the ex-
ternal keyboard (option) can be used.
When you turn on the check box, a check mark (
;
) appears inside
the box, indicating that the configuration of the system will be
changed to make the external keyboard available.
*1
0106-002 Chapter 1 4 15 AFU01EDTP
2.4
"
Option Setting
"
Tab
0106-001 Chapter 1 4 15-1 AFU01EDTP
2.5 “Date/Time” Tab
The corresponding tab sheet enables the operator to set the current
date and time.
• Sheet Layout
When the “Date/Time” tab is pressed in the “MAC. SET-UP” window
(submenu), the following tab sheet appears.
Fig. 3D10-1 “Date/Time” Tab Sheet
• Sheet Composition
*1 Now Date & Time
Displayed are the current date and time.
*2 Year, Month, Day, Hour, Minute, Second
Set the date and time in each text box.
*3 Time Zone
Set the time zone in the text box.
Example: When the machine is used in Japan, select
“(GMT+09:00) Tokyo, Seoul” from the drop-down list of
the combo box.
2.5 “Date/Time” Tab
