Fig. 5A14 P .C.B. Chuck Section Fig. 5A14-1 Chuck Section 6. Monthly Maintenance Backup T able Z Axis Guide Bushing Clean the guide bushing with an oiled rag. Note: Remove waste thread if any . Cleaning Linear Guide for …
Fig. 5A12 Table Section
Fig. 5A13 Table Section
6. Monthly Maintenance
0004-001 Chapter 3 1 14 AFU01EINP
X-Axis Linear Guide
Clean the guide with an oiled
rag.
Note: Remove waste thread
if any.
Cleaning
Z-Axis Guide Bushing
Cleaning
Clean the bushing with an
oiled rag.
Note: Remove waste thread
if any.
-Axis Linear Guide
Clean the guide with an oiled
rag.
Note: Remove waste thread
if any.
Cleaning
Fig. 5A14 P.C.B. Chuck Section
Fig. 5A14-1 Chuck Section
6. Monthly Maintenance
Backup Table Z Axis Guide
Bushing
Clean the guide bushing with
an oiled rag.
Note: Remove waste thread
if any.
Cleaning
Linear Guide for Chute Width
Adjustment
Cleaning
Clean the guide with an oiled
rag.
Note: Remove waste thread
if any.
Linear Guide for P.C.B.
Clamping
Cleaning
Clean the guide with an oiled
rag.
Note: Remove waste thread
if any.
0009-002 Chapter 3 1 15 AFU01EINP
Fig. 5A15 P.E.C. Recognition Section
Fig. 5A16 P.E.C. Recognition Section
Fig. 5A17 Squeegee Head Section
X-Axis Linear Guide
Clean the guide with an oiled
rag.
Note: Remove waste thread
if any.
Cleaning
Clean the guide with an oiled
rag.
Note: Remove waste thread
if any.
Cleaning
Y-Axis Linear Guide
Clean the guide with an oiled
rag.
Note: Remove waste thread
if any.
Cleaning
Y-Axis Linear Guide
0009-002 Chapter 3 1 16 AFU01EINP
6. Monthly Maintenance
