1.2.9 Cleaning T able 3A10 Data Item Referential Items Cleaning Area (1) in 1.2.9 of 2 Cleaning Interval (2) in 1.2.9 of 2 Cleaning Mode (3) in 1.2.9 of 2 Standard Mode (4) in 1.2.9 of 2 Option Mode (5) in 1.2.9 of 2 Cle…

100%1 / 387
1.2.5 Screen Recognition
Table 3A6
Data Item Referential Items
Screen Recognition Function (1) in 1.2.5 of
2
Center Recognition (2) in 1.2.5 of
2
Fiducial Mark #1 (3) in 1.2.5 of
2
Fiducial Mark #2 (4) in 1.2.5 of
2
1.2.6 Mark Data
Table 3A7
Data Item Referential Items
Code (1) in 1.2.6 of 2
Figure (2) in 1.2.6 of
2
Size D1, Size D2 (3) in 1.2.6 of
2
Recognition Area (4) in 1.2.6 of
2
Polarity (5) in 1.2.6 of
2
Level (6) in 1.2.6 of
2
Lighting (7) in 1.2.6 of
2
1.2.7 Setup Data
Table 3A8
Data Item Referential Items
All Conveyor Setup (1) in 1.2.7 of 2
Two Camera Auto Calibration (2) in 1.2.7 of
2
Screen Recognition (3) in 1.2.7 of
2
1.2.8 Auto Stop
Table 3A9
Data Item Referential Items
Hand Cleaning Stop (PCB) (1) in 1.2.8 of 2
Hand Cleaning Stop (CLNG.) (2) in 1.2.8 of
2
Solvent Empty Stop (CLNG.) (3) in 1.2.8 of
2
Paste Supply Interval Mode (4) in 1.2.8 of
2
Paste Empty Stop (PCB) (5) in 1.2.8 of
2
Paste Detection (Option) (6) in 1.2.8 of
2
1.2 Offset Data
0106-003 Chapter 1 1 5 AFU01EDTP
1.2.9 Cleaning
Table 3A10
Data Item Referential Items
Cleaning Area (1) in 1.2.9 of
2
Cleaning Interval (2) in 1.2.9 of
2
Cleaning Mode (3) in 1.2.9 of
2
Standard Mode (4) in 1.2.9 of
2
Option Mode (5) in 1.2.9 of
2
Cleaning Speed [mm/sec] (6) in 1.2.9 of
2
Paper Feed Pitch [mm] (7) in 1.2.9 of
2
Solvent Dispense Time [Sec] (8) in 1.2.9 of
2
1.2 Offset Data
0004-001 Chapter 1 1 6 AFU01EDTP
1.3 Various Data
The following data is required for printing in addition to the pattern pro-
gram.
Fig. 3A2
1.3.1 Management Data
The management data is composed of the following data.
Refer to "Section 3 Menus for Management Data" for details.
Table 3A11
Data Item Referential Items
Management Data 1 2 in
3
Management Data 2 2 in
3
Program Management Data 3 in
3
1.3.2 Machine Set-Up
The machine set-up data is composed of the following data.
Refer to "2. "Machine Set-Up" Submenu" in "Section 4 Menus for Sys-
tem Setting" for details.
Table 3A12
Data Item Referential Items
Password 2.1 in
4
Tower Lamp
Buzzer Set-up 2.2 in 4
Display Setting 2.3 in
4
Option Setting 2.4 in
4
Date/Time 2.5 in
4
0106-002 Chapter 1 1 7 AFU01EDTP
1.3 Various Data
