Error ID Item Description
1607000 System Error Failed to calculate position.
(Cause 1) Self-Diagnostics Error Message
(Cause 2) The amount of the recognition correction has exceeded the limited value
(10 mm twice).
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
(Remedy 2) Check the coordinates of the fiducial mark and the value for printing inac-
curacy correction.
1608000 Node Error Operation Node (1) Error
1609000 Node Error Relay Sequence Node (2) Error
1610000 Node Error Inp.& Outp.Mac. Interface Node (3) Error
1611000 Node Error P.C.B. Transfer Node (4) Error
1612000 Node Error P.C.B. Chuck Node (5) Error
1613000 Node Error Squeegee Head Node (6) Error
1614000 Node Error P.E.C Recog. Node (7) Error
1615000 Node Error Cleaning Unit Node (8) Error
1616000 Node Error Blower Unit Node (9) Error
1617000 Node Error Printing pressure control output node error
1618000 Node Error Printing pressure control input node error
(Cause 1) Node (N001) failed in the communication with the host computer.
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 57 AFU01ETRP
Error ID Item Description
1619000 Pattern Program
Data Error
1620000 Pattern Program
Data Error
1621000 Pattern Program
Data Error
1622000 Pattern Program
Data Error
1623000 Pattern Program
Data Error
1624000 Pattern Program
Data Error
1625000 Pattern Program
Data Error
1626000 Pattern Program
Data Error
1627000 Pattern Program
Data Error
1628000 Pattern Program
Data Error
1629000 Pattern Program
Data Error
1630000 Pattern Program
Data Error
(Cause 1) The motor controller node (APMD017) failed in the communication with the
host computer.
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 58 AFU01ETRP
Error ID Item Description
1631000 Pattern Program Illegal pattern program
Data Error
(Cause 1) An illegal value is set in pattern program data.
(Remedy 1) Press the [PRGM. CHECK] button in the "ERROR" window and check
the contents. After that, set the correct value(s).
1701000 Squeegee Life Front squeegee exceeded life limit.
(Cause 1) The frequency of the front squeegee use has exceeded the limitation.
(Remedy 1) Change the front squeegee and select the "Printed" data field of the re-
placed squeegee in the "Auto Stop Info" tab sheet. After that, press the
[Counter Clear] button.
1702000 Squeegee Life Rear squeegee exceeded life limit.
(Cause 1) The frequency of the rear squeegee use has exceeded the limitation.
(Remedy 1) Change the rear squeegee and select the "Printed" data field of the re-
placed squeegee in the "Auto Stop Info" tab sheet. After that, press the
[Counter Clear] button.
1801000 Fiducial Mark #1
1801001 Fiducial Mark #1 [Camera ID] exceeds the range of setting.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If the machine is not reset to its normal condition, shut down the power of
the machine once and power up the machine again. After that, re-start
the operation.
When the same error still occurs, contact our service personnel for de-
tails.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 59 AFU01ETRP
