1. Pattern Program Data Sheets

Pattern Program Date of Preparation

Comment 1 Prepared by

Comment 2

(1) Operation Data

P.C.B. Data

P.C.B. Size X (Horizontal)

Y (Vertical)

T (Thickness)

P.C.B. Origin Offset X (Horizontal) +/-

Y (Vertical) +/-

Operation Mode Print/Pass

Print Area Origin +/-

Depth +/-

Print Data

Screen Basis Center Reference/Front Reference

/Rear Reference

Round-Way Printing ON/OFF

Frame Select 650×550/550×550/600×550/550×650

Printing Press. [N] Front N

Rear N

Squeegee Select 270/350

Squeegee Spd. For.

Back.

Screen Distance +/-

Separation Mode PCB Down/Squeegee Up

Separation Speed

Separation Acc.

Separate Distance

Prntng Correction (Back) X +/-

Y +/-

θ +/-

Prntng Correction (For.) X +/-

Y +/-

θ +/-

Screen Offset [mm] X +/-

Y +/-
