Error ID Item Description 1001000 T able Chute Width Zeroing opn. was incompleted, within specified time. Origin (Cause 1) Dirt adheres to the sensor and the optical beam is shielded. (Cause 2) The sensor is defective. (…
Error ID Item Description
0909000 P.C.B. Backup Axis Operation was incompleted, within specified time.
Driver
(Cause 1) The driver is malfunctioning or an error has occurred during communication
with the host CPU.
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, perform the zeroing operation.
If this operation does not reset the machine to its normal condition, the
driver may be defective. Contact our service personnel for details.
0911000 P.C.B. Backup Axis Task has not been completed unable to continue.
Timing
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If the machine is not reset to its normal condition, shut down the power of
the machine once and power up the machine again. After that, re-start
the operation.
When the same error still occurs, contact our service personnel for de-
tails.
0912000 P.C.B. Backup Axis The data was detected outside of the possible range.
Data
(Cause 1) The specified data may have exceeded the movable range.
(Remedy 1) Check the parameter in the "P.C.B. Chuck Height" text box ("OFFSET
DATA" window).
0913000 P.C.B. Backup Axis Zeroing Opn. Not Complete
Origin
(Cause 1) The motor axis was activated before the zeroing operation was completed.
(Remedy 1) Perform the zeroing operation.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 37 AFU01ETRP
Error ID Item Description
1001000 Table Chute Width Zeroing opn. was incompleted, within specified time.
Origin
(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 2) The sensor is defective.
(Cause 3) The driver is malfunctioning or an error has occurred during communication
with the host CPU.
(Remedy 1) Wipe off dirt on the sensor and zero the table chute width axis again.
(Remedy 2) It is required to replace the sensor with a new one. Contact our service
personnel for details.
(Remedy 3) Shut down the power of the machine once and power up the machine
again. After that, perform the zeroing operation.
If this operation does not reset the machine to its normal condition, the
driver may be defective. Contact our service personnel for details.
1002000 Table Chute Width Detect lost pulse error.
Origin
(Cause 1) The motor is overloaded and has a loss of synchronism.
(Remedy 1) Check for any obstacle around the P.E.C. recognition X axis and perform
the zeroing operation.
If this operation does not reset the machine to its normal condition, con-
tact our service personnel for details.
1008000 Table Chute Width Driver Over-Heat
Driver
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If this operation does not reset the machine to its normal condition, con-
tact our service personnel for details.
0106-001 Chapter 2 2 38 AFU01ETRP
2.3 Error IDs and Remedial Procedures
Error ID Item Description
1009000 Table Chute Width Operation was incompleted, within specified time.
Driver
(Cause 1) The driver is malfunctioning or an error has occurred during communication
with the host CPU.
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, perform the zeroing operation.
If this operation does not reset the machine to its normal condition, the
driver may be defective. Contact our service personnel for details.
1012000 Table Chute Width PCB Backup Axis is not at origin.
Interlock
(Cause 1) The P.C.B. backup axis origin sensor (BPH231) is defective.
(Cause 2) The operation timing is shifted from the normal one.
(Cause 3) The table chute width axis was activated after the P.C.B. backup axis had
moved up. (during the manual operation)
(Remedy 1) Check how the sensor is working in "Device Check" window (submenu).
When the sensor is not working, it is required to replace the sensor with
a new one. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine
again. After that, restart the operation. When the same error still occurs,
contact our service personnel for details.
(Remedy 3) Perform the zeroing operation and re-start the operation.
1013000 Table Chute Width P.C.B. warpage protection was down.
Interlock
(Cause 1) The table chute width axis was activated after the P.C.B. warpage protec-
tion had moved down.
(Remedy 1) Move up the P.C.B. warpage protection and re-start the operation.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 39 AFU01ETRP
