Error ID Item Description
1801029 Fiducial Mark #1 Image around fiducial mark was unstable.
1801030 Fiducial Mark #1 Error of mark figure similitude was extensive.
1801031 Fiducial Mark #1 Error of mark similitude or mark size was extensive.
1801032 Fiducial Mark #1 Specified mark was not found in window of recog.monitor.
(Cause 1) The fiducial marks do not conform to the coordinates X and Y of the fiducial
marks or the recognition mark data in the pattern program.
(Remedy 1) Follow the steps below to reset the machine to the normal condition.
(1) When the [RESET] button is pressed, the following window opens.
(2) When the actual fiducial mark is out of the recognition area, move
the camera such that the mark can enter the recognition area.
Select the [Eye Adjust [START]] button and press one of the arrow
buttons in the "DIRECTION" and "SPEED" boxes. While the [START]
button is being pressed, the camera keeps on moving.
(3) Select the [Retry Recog.[START]] button and press the [START] but-
ton.
When the recognition is completed successfully, this window auto-
matically closes.
(4) When the recognition still failed after the re-recognition operation,
move the camera such that the actual fiducial mark can stay at the
fiducial mark template (located at the center of the cross hair).
Note: Be sure to adjust the position of the fiducial mark as accu-
rately as possible because the printing accuracy is affected by
this adjustment.
(5) Select the [Eye Adjust Finished [START]] button and press the
[START] button.
The original window resumes.
If the [STOP] button is pressed while the "Eye Adjust" window is
active, the processing is interrupted and the original window re-
sumes.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 61 AFU01ETRP
Error ID Item Description
1801038 Fiducial Mark #1 Unavailable fiducial mark polality was set.
1801040 Fiducial Mark #1 Unavailable fiducial mark area was set.
1801043 Fiducial Mark #1 Recognition system error.
1801056 Fiducial Mark #1 Recog. transaction time over.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
1802000 Fiducial Mark #2 (Same as "Fiducial Mark #1")
Cause 1) Same as "Fiducial Mark #1"
(Remedy 1) Same as "Fiducial Mark #1"
1804000 P.E.C. Recognition (Same as "Fiducial Mark #1")
Test
(Cause 1) Same as "Fiducial Mark #1"
(Remedy 1) Same as "Fiducial Mark #1"
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 62 AFU01ETRP
Error ID Item Description
1806000 P.E.C. Recognition (Same as "Fiducial Mark #1")
Camera
1807000 Recognition (Same as "Fiducial Mark #1")
Processing
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
1901000 Screen Fiducial
Mark #1
1901001 Screen Fiducial [Camera ID] exceeds the range of setting.
Mark #1
1901002 Screen Fiducial [Camera Offset X] exceeds the range of setting.
Mark #1
1901003 Screen Fiducial [Camera Gain] exceeds the range of setting.
Mark #1
1901004 Screen Fiducial [Camera Level] exceeds the range of setting.
Mark #1
(Cause 1) Same as "Fiducial Mark #1"
(Remedy 1) Same as "Fiducial Mark #1"
