Error ID Item Description 041 1000 Screen Y Interlock T able-Z Axis is not at safety area. (Cause 1) The table Z axis interlock sensor (BPH055) is defective. (Cause 2) The operation timing is shifted from the normal one.…
Error ID Item Description
0408000 Screen Y Servo Driver Over-Heat
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If this operation does not reset the machine to its normal condition, con-
tact our service personnel for details.
0409000 Screen Y Servo Operation was incompleted, within specified time.
(Cause 1) The driver is malfunctioning or an error has occurred during communication
with the host CPU.
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, perform the zeroing operation.
If this operation does not reset the machine to its normal condition, the
driver may be defective. Contact our service personnel for details.
0410000 Screen Y Interlock Cleaning nozzle is up.
(Cause 1) The cleaning nozzle lower limit sensor (BPS081) is defective.
(Cause 2) The operation timing is shifted from the normal one.
(Cause 3) The screen Y axis was activated after the cleaning nozzle had moved up.
(during the manual operation)
(Remedy 1) Check how the sensor is working in “Device Check” window (submenu).
When the sensor is not working, it is required to replace the sensor with
a new one. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
(Remedy 3) Perform the zeroing operation and re-start the operation.
2.3 Error IDs and Remedial Procedures
0106-002 Chapter 2 2 21 AFU01ETRP
Error ID Item Description
0411000 Screen Y Interlock Table-Z Axis is not at safety area.
(Cause 1) The table Z axis interlock sensor (BPH055) is defective.
(Cause 2) The operation timing is shifted from the normal one.
(Cause 3) The screen Y axis was activated after the table Z axis had moved up.
(during the manual operation)
(Remedy 1) Check how the sensor is working in “Device Check” window (submenu).
When the sensor is not working, it is required to replace the sensor with
a new one. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
(Remedy 3) Perform the zeroing operation and re-start the operation.
0414000 Screen Y Timing Task has not been completed unable to continue.
0415000 Screen Y Data The data was detected outside of the possible range.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
If the machine is not reset to its normal condition, shut down the power of
the machine once and power up the machine again. After that, re-start
the operation.
When the same error still occurs, contact our service personnel for de-
tails.
0416000 Screen Y Origin Zeroing Opn. Not Complete
(Cause 1) The motor axis was activated before the zeroing operation was completed.
(Remedy 1) Perform the zeroing operation.
2.3 Error IDs and Remedial Procedures
0106-002 Chapter 2 2 22 AFU01ETRP
Error ID Item Description
0501000 Squeegee Driving Zeroing opn. was incompleted, within specified time.
Origin
(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 2) The sensor is defective.
(Cause 3) The driver is malfunctioning or an error has occurred during communication
with the host CPU.
(Remedy 1) Wipe off dirt on the sensor and zero the squeegee driving axis again.
(Remedy 2) It is required to replace the sensor with a new one. Contact our service
personnel for details.
(Remedy 3) Shut down the power of the machine once and power up the machine
again. After that, perform the zeroing operation.
If this operation does not reset the machine to its normal condition, the
driver may be defective. Contact our service personnel for details.
0502000 Squeegee Drive Detect lost pulse error.
Origin
(Cause 1) The motor is overloaded and has a loss of synchronism.
(Remedy 1) Check for any obstacle around the squeegee driving axis and then per-
form the zeroing operation.
If this operation does not reset the machine to its normal condition, con-
tact our service personnel for details.
0503000 Squeegee Driving (+) Limit error has been detected.
Limit
(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 2) The sensor is defective.
(Cause 3) The driver is malfunctioning or an error has occurred during communication
with the host CPU.
(Remedy 1) Wipe off dirt on the sensor and zero the squeegee driving axis again.
(Remedy 2) It is required to replace the sensor with a new one. Contact our service
personnel for details.
(Remedy 3) Shut down the power of the machine once and power up the machine
again. After that, perform the zeroing operation.
If this operation does not reset the machine to its normal condition, the
driver may be defective. Contact our service personnel for details.
2.3 Error IDs and Remedial Procedures
0106-002 Chapter 2 2 23 AFU01ETRP
