2. "MANAGE. DA T A 1" Submenu The " MANAGE. DA T A 1 " and " MANGE. DA T A 2 " windows (submenu) are composed of the same tab sheets. Each data must be used discriminatingly so as to calcula…
1.1.1 Submenus and Tab Sheets
The "MANAGE. DATA" window is provided with the following 3 submenu
buttons.
MANAGEMENT DATA
Submenus Tabs Reference Item Nos.
MANAGE. DATA 1 Product (2.1)
Time Data (2.2)
Recog. Error (2.3)
Sub-System Error (2.4)
Info. Clear (2.5)
MANAGE DATA 2 Product (2.1)
Time Data (2.2)
Recog. Error (2.3)
Sub-System Error (2.4)
Info. Clear (2.5)
PRGM. MNG. DATA Prgm. Chg. & Clear (3.1)
Prod. History (3.2)
Product (3.3)
Time Data (3.4)
Recog. Error (3.5)
Note: The numbers in ( ) represent Nos. of items which can be re-
ferred to for details.
Fig. 3C2
The
"MANAGE. DATA 1" and "MANGE. DATA 2" windows (submenu)
are composed of the same tab sheets.
Each data must be used discriminatingly so as to calculate the manage-
ment data (classified into monthly and daily cumulative data) during dif-
ferent periods of time (time specified separately).
Refer to "2. "MANAGE DATA 1" Window (Submenu)" for the compo-
sition of the tab sheets in the "MANAGE DATA 2" window.
0004-001 Chapter 1 3 3 AFU01EDTP
1.1 Composition of Menus for Management Data
2. "MANAGE. DATA 1" Submenu
The "MANAGE. DATA 1" and "MANGE. DATA 2" windows (submenu)
are composed of the same tab sheets.
Each data must be used discriminatingly so as to calculate the manage-
ment data (classified into monthly and daily cumulative data) during dif-
ferent periods of time (time specified separately).
• Window Layout
When the [MANAGE. DATA 1] button is pressed in the "MANAGE.
DATA" submenu bar, the following window appears.
Fig. 3C3 "MANAGE. DATA 1" Window (Submenu)
• Window Composition
*1 Tabs
The "MANAGE. DATA 1" window (submenu) has 5 tab sheets.
When a tab is pressed, the corresponding tab sheet appears.
0004-001 Chapter 1 3 4 AFU01EDTP
2.
"
MANAGE. DATA 1
"
Submenu
*1
Table 3C1
Tabs Description
Product This indicates the data that represents the actual production rate of
the machine.
Time Data This indicates the data that represents the cumulative periods of
running time for each operation mode.
Recog. Error This indicates the data related to the recognition errors.
Sub-System Error This indicates the error data on each individual units.
Info. Clear This tab sheet is provided with two buttons and each button is used
to clear the management data stored in memory.
