2.2 Error IDs and Controlled Areas Basic System of Error IDs An error ID is expressed by 7 digits (decimal number) as follows.  Major Classification of "Operating Axis", "Process Error", and &q…

2.1 Typical Description

Table 4B4

Error ID Item Description

110401 L Conveyor Width Overrun The plus (+) overrun was detected.

(BPH77) E/NR (+)

E/NR: Light Emitted and Not Received

110402 L Conveyor Width Overrun The minus (-) overrun was detected.

(BPH77) E/NR (-)

(Cause 1) An optical beam of the sensor is shielded.

(Cause 2) Dirt adheres to the sensor and the optical beam is shielded.

(Cause 3) The sensor is defective.

(Remedy 1) Turn off the power supply and move the conveyor width with the manual

knob for easier operation. Re-attach the light shield plate or the sensor

securely (remove the looseness).

(Remedy 2) Wipe off dirt on the sensor and zero the L conveyor again.

(Remedy 3) Replace the sensor with a new one.

120101 R Conveyor Width Origin The excitation monitor signal was not de-

tected.

(Cause 1)

(Remedy 1)

(Continued to the next page)

*1 The error IDs (IDs displayed in the "ERROR" window) are described

in the numerical order.

*2 Described are the classification (ITEM) and explanation (CONTENT)

in the "ERROR" window.

*3 Described are the causes and remedial procedures of the errors in

"*2 (Classification and Explanation)".

The causes and remedies are correlated as follows.

(Cause 1)

ÆÆ

Æ (Remedy 1)

(Cause 2)

ÆÆ

Æ (Remedy 2)

(Cause 3)

ÆÆ

Æ (Remedy 3)

*4 This indicates that the related contents are described subsequently

on the next page.

2.1 Typical Description

0009-001 Chapter 2 2 6 AFU01ETRP

2.2 Error IDs and Controlled Areas

Basic System of Error IDs

An error ID is expressed by 7 digits (decimal number) as follows.



Major Classification of "Operating Axis", "Process Error", and

"Teaching Operation"

Error IDs and Controlled Areas

Table 4B5

Error ID Operating Axis Error ID Process Error

01 Table-X Axis 15 Safety Device

02 Table-Z Axis 16 Self-Diagnostics

03 Placement Z Correction Table

Axis 17 Material Shortage

04 Screen Y Axis 18 P.C.B. Recognition

05 Squeegee Driving Axis 19 Screen Recognition

06 P.E.C. Recognition Camera X Axis 20 Cleaning

07 P.E.C. Recognition Camera Y Axis 21 Operator’s Error

08 Screen Recognition Camera X Axis 22 Others

09 P.C.B. Backup Axis

10 Table Chute Width

11 Input Conveyor

12 Output Conveyor

13 P.C.B. Transfer

14 Squeegee Head

2.2 Error IDs and Controlled Areas

0009-001 Chapter 2 2 7 AFU01ETRP

2.3 Error IDs and Remedial Procedures

Error ID Item Description

0101000 Table X Origin Zeroing opn. was incompleted, within specified time.

(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.

(Cause 2) The sensor is defective.

(Cause 3) The driver is malfunctioning or an error has occurred during communication

with the host CPU.

(Remedy 1) Wipe off dirt on the sensor and zero Table X again.

(Remedy 2) It is required to replace the sensor with a new one. Contact our service

personnel for details.

(Remedy 3) Shut down the power of the machine once and power up the machine

again. After that, zero Table X.

If this operation does not reset the machine to its normal condition, the

driver may be defective. Contact our service personnel for details.

0102000 Table X Origin Detect lost pulse error.

(Cause 1) The motor is overloaded and has a loss of synchronism.

(Remedy 1) Check for any obstacle around the table X axis and then perform the

zeroing operation.

If this operation does not reset the machine to its normal condition, con-

tact our service personnel for details.

0103000 Table X Limit (+) Limit error has been detected.

0104000 Table X Limit (-) Limit error has been detected.
