0106-002 Chapter 3 3 55 AFU01EDTP 3.6 Location of Sensor in Screen Recognition Section 3.6 Location of Sensor in Screen Recognition Section Fig. 5C1 1 T able 5C7 Symbols Name BPH31 1 Screen Recognition X-Axis Origin BPH3…
0106-002 Chapter 3 3 54 AFU01EDTP
Fig. 5C10
Table 5C6
Symbols Name
B001 Front Load Cell
B002 Rear Load Cell
BPS060 Front Squeegee U/D Upper Limit
BPS061 Front Squeegee U/D Middle
BPS062 Rear Squeegee U/D Upper Limit
BPS063 Rear Squeegee U/D Middle
BPH064 Paste Height Detection (Option)
BPH271 Squeegee Driving Axis Origin
BPH272 Squeegee Driving Axis Limit
BPH274 Squeegee Driving Axis Rotational Origin
MPM027 Squeegee Driving Axis Pulse Motor
YSV068 Front Squeegee U/D Solenoid Valve
YSV069 Rear Squeegee U/D Solenoid Valve
YSV06A Squeegee Middle Stopper (Outward)
3.5 Location of Sensors in Squeegee Section
0106-002 Chapter 3 3 55 AFU01EDTP
3.6 Location of Sensor in Screen Recognition Section
3.6 Location of Sensor in Screen Recognition Section
Fig. 5C11
Table 5C7
Symbols Name
BPH311 Screen Recognition X-Axis Origin
BPH314 Screen Recognition X-Axis Rotational Origin
MPM031 Screen Recognition X-Axis Pulse Motor
4. Electrical Circuit Diagrams
4.1 Electrical and Electronic Symbols
Part Name Symbol Part Name Symbol
Servomotor Driver A** General AC Motors, etc. M**
Stepping Motor Driver A** Stepping Motor M**
Speed Control Pack A** Servomotor M**
Recognition Monitor A** Fan Motor M**
Touch Screen A** Measuring Instrument P**
Thermocouple B** Breaker for Wiring Q**
Camera B** Circuit Breaker, Q**
Photosensor B** Circuit Protector
Proximity Sensor B** Resistor R**
Position Switch B** Semi-Fixed Resistor R**
Capacitor C** Variable Resistor R**
Hard Disk Drive D** Switch S**
HDD Pushbutton Switch S**
Floppy Disk Drive D** Limit Switch S**
FDD Door Switch S**
Heater E** Pressure Switch S**
Lighting Unit E** Vacuum Switch
Recognition Lighting E** (Vacuum Sensor)
Discharging Gap F** Transformer T**
Lightning Surge Protector F** P.C.B. A**
Fuse F** Inverter U**
Thermal Relay F** Diode V**
Battery G** Transistor V**
Switching Power Supply G** IC V**
Servomotor Brake Power Supply Cable W**
Buzzer H** Plug, Socket X**
Bell H** Connector X**
Indicator Lamp H** Metal Connector X**
Positioning Lamp H** Nylon Connector X**
Relay K** Terminal X**
Timer Relay K**T Solenoid Valve Y**
Electromagnetic Contactor K**M Solenoid Y**
Electromagnetic Switch K**M Brake Y**
(Electromagnetic Contactor+ &F** Clutch Y**
Thermal Relay) Filter Z**
Solid-State-Relay K** Noise Filter Z**
Inductance, Coil L** Spark Killer Z**
0004-001 Chapter 3 3-56 AFU01EMTP
4.1 Electrical and Electronic Symbols
