Error ID Item Description
1806000 P.E.C. Recognition (Same as "Fiducial Mark #1")
Camera
1807000 Recognition (Same as "Fiducial Mark #1")
Processing
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
1901000 Screen Fiducial
Mark #1
1901001 Screen Fiducial [Camera ID] exceeds the range of setting.
Mark #1
1901002 Screen Fiducial [Camera Offset X] exceeds the range of setting.
Mark #1
1901003 Screen Fiducial [Camera Gain] exceeds the range of setting.
Mark #1
1901004 Screen Fiducial [Camera Level] exceeds the range of setting.
Mark #1
(Cause 1) Same as "Fiducial Mark #1"
(Remedy 1) Same as "Fiducial Mark #1"
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 63 AFU01ETRP
Error ID Item Description
1901005 Screen Fiducial [Camera Mag. X] exceeds the range of setting.
Mark #1
1901006 Screen Fiducial [Camera Mag. Y] exceeds the range of setting.
Mark #1
1901007 Screen Fiducial [Gain, Level] exceeds the range of setting.
Mark #1
1901008 Screen Fiducial [Mark] exceeds the range of setting.
Mark #1
1901009 Screen Fiducial [Mark Code] exceeds the range of setting.
Mark #1
1901010 Screen Fiducial [Mark Code] exceeds the range of setting.
Mark #1
1901011 Screen Fiducial [Mark Size D1] exceeds the range of setting.
Mark #1
1901012 Screen Fiducial [Mark Size D2] exceeds the range of setting.
Mark #1
1901013 Screen Fiducial [Mark Pol.] exceeds the range of setting.
Mark #1
1901014 Screen Fiducial [Mark Judge Level] exceeds the range of setting.
Mark #1
1901015 Screen Fiducial [PCB Pattern ID] exceeds the range of setting.
Mark #1
1901016 Screen Fiducial [P.E.C Recog. Offset] exceeds the range of setting.
Mark #1
1901017 Screen Fiducial [P.E.C Recog. Gain] exceeds the range of setting.
Mark #1
1901018 Screen Fiducial [Jig Size X] exceeds the range of setting.
Mark #1
1901019 Screen Fiducial [Jig Size Y] exceeds the range of setting.
Mark #1
1901020 Screen Fiducial [Jig Figure] exceeds the range of setting.
Mark #1
1901021 Screen Fiducial [Jig Line Width] exceeds the range of setting.
Mark #1
1901022 Screen Fiducial [Algorism] exceeds the range of setting.
Mark #1
1901023 Screen Fiducial [Recog.Area X] exceeds the range of setting.
Mark #1
(Cause 1) Same as "Fiducial Mark #1"
(Remedy 1) Same as "Fiducial Mark #1"
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 64 AFU01ETRP
Error ID Item Description
1901024 Screen Fiducial [Recog.Area Y] exceeds the range of setting.
Mark #1
1901025 Screen Fiducial [Color] exceeds the range of setting.
Mark #1
1901026 Screen Fiducial Could not get Screen image.
Mark #1
1901027 Screen Fiducial X-cordinate error of measuring point was extensive.
Mark #1
1901028 Screen Fiducial Y-cordinate error of measuring point was extensive.
Mark #1
1901029 Screen Fiducial Image around fiducial mark was unstable.
Mark #1
1901030 Screen Fiducial Error of mark figure similitude was extensive.
Mark #1
1901031 Screen Fiducial Error of mark similitude or mark size was extensive.
Mark #1
1901032 Screen Fiducial Specified mark was not found in window of recog.monitor.
Mark #1
1901033 Screen Fiducial Unavailable camera magnification was set.
Mark #1
1901034 Screen Fiducial Abnormal data was transferred to recog.unit.
Mark #1
1901035 Screen Fiducial Unavailable fiducial mark code was set.
Mark #1
1901036 Screen Fiducial Unavailable fiducial mark size D1 was set.
Mark #1
1901037 Screen Fiducial Unavailable fiducial mark size D2 was set.
Mark #1
1901038 Screen Fiducial Unavailable fiducial mark polality was set.
Mark #1
1901039 Screen Fiducial Unavailable fiducial mark angle was set.
Mark #1
1901040 Screen Fiducial Unavailable fiducial mark area was set.
Mark #1
1901041 Screen Fiducial JIG not found
Mark #1
(Cause 1) Same as "Fiducial Mark #1"
(Remedy 1) Same as "Fiducial Mark #1"
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 65 AFU01ETRP
