Error ID Item Description 1501000 Load Power ޣ ޣ ޣ ޣ ޣ Emergency ޤ ޤ ޤ ޤ ޤ button pressed. Shut-Off (Cause 1) An [EMERGENCY STOP] button was pressed. (Remedy 1) Unlock the [EMERGENCY STOP] button and hold down the [POWER…
Error ID Item Description
1409000 Printing Pressure Printing pressure exceeded upper range. (Peak)
Setting
(Cause 1) The printing pressure was not constant temporarily.
(Cause 2) The output value of the load cell is abnormal.
(Remedy 1) Check for any foreign substances on the production P.C.B. and the screen.
(Remedy 2) Check for any foreign substances near the load cell.
When the same error still occurs, contact our service personnel for de-
tails.
1410000 Squeegee Up/Down Squeegee up/down cylinder, Squge.Y axis was not at
Interlock safety area.
(Cause 1) The range of the squeegee movement has exceeded the limited one.
(Remedy 1) Check if the parameters in the "Origin" and "Depth" text boxes of "Print
Area" in the P.C.B. Data" tab sheet ("Pattern Program" window) and the
parameters in the "Paste Size" and "Print Margin" group boxes in the
"Printing Condition" tab sheet ("OPN. MODE" window) are too large or
not.
1411000 Squeegee Up/Down Squeegee up/down cylinder, PCB was not exist on table.
Interlock
(Cause 1) The squeegee was moved down when no P.C.B. was on the table.
(during the manual operation)
(Remedy 1) Move up the table with a P.C.B. being clamped in the table section and
re-start the operation.
1412000 Squeegee Up/Down Squeegee up/down cylinder, PCB was not checked.
Interlock
(Cause 1) The squeegee was moved down when a P.C.B. was not clamped on the
table. (during the manual operation)
(Remedy 1) Clamp the P.C.B. in the table section and move up the table. After that,
re-start the operation.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 54 AFU01ETRP
Error ID Item Description
1501000 Load Power
ޣޣ
ޣޣ
ޣ
Emergency
ޤޤ
ޤޤ
ޤ
button pressed.
Shut-Off
(Cause 1) An [EMERGENCY STOP] button was pressed.
(Remedy 1) Unlock the [EMERGENCY STOP] button and hold down the [POWER
ON] button for more than 3 seconds. After that, press the [RESET] button
in the "ERROR" window.
1502000 Load Power The air pressure is too low.
Shut-Off
(Cause 1) The main air pressure had dropped below 0.4 MPa (the set value of the
pressure switch).
(Remedy 1) Adjust the pressure to the correct one.
1503000 Load Power The safety door is open.
Shut-Off
(Cause 1) The safety door was opened.
(Remedy 1) Close the safety door and hold down the [POWER ON] button for more
than 3 seconds. After that, press the [RESET] button on the touch screen.
Power up the machine again and re-start the operation.
1504000 Load Power Detected circuit breaker off.
Shut-Off
(Cause 1) The circuit breaker of Q100, Q202, Q203 or Q204 is turned OFF.
(Remedy 1) Contact our service personnel for details.
1505000 Load Power Detected all load power monitor off.
Shut-Off
(Cause 1) The load power supply monitor (K021) is turned OFF.
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
If possible, check how the fuse (F001), K14, K15, K16, KM100, and KM200
are working.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 55 AFU01ETRP
Error ID Item Description
1506000 Load Power Detected load power monitor off.
Shut-Off
(Cause 1) All load power supply monitor (K22) is turned OFF.
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
If possible, check how the fuse (F001), K14, K15, K16, KM100, and KM200
are working.
1601000 Control P.C.B. System error
1602000 Control P.C.B. Control board error
(Cause 1) An error has occurred in the SDS communication.
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
1603000 Sensor Paste detect sensor error
(Cause 1) The paste height detection sensor (BPH064) is not adjusted correctly.
(Remedy 1) Contact our service personnel for details.
1604000 System Error Undefined Error
1605000 System Error Illegal error code
1606000 System Error Internal data error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine
again. After that, restart the operation.
When the same error still occurs, contact our service personnel for de-
tails.
2.3 Error IDs and Remedial Procedures
0106-001 Chapter 2 2 56 AFU01ETRP
